CONTROL SYSTEM WIRING DIAGRAM
See ENGINE PERFORMANCE .
Scheme 399
- Disconnect the negative battery cable.
- Remove the TCM. (See TCM REMOVAL/INSTALLATION .)
- Remove in the order indicated in the illustration.
- Install in the reverse order of removal.
Scheme 400
- Disconnect the front blower resistor connector.
- Remove the air duct stay fastener.
- Slide the air duct to the right.
- Tilt the left side down to remove the air duct from the installation place.
Scheme 401
Scheme 402
- Before removing the PCM panel, pull the PCM connector harness stay fastener out from the PCM panel.
- Remove the upper right side of the PCM panel installation nut located at the back of the blower unit as shown.
- Remove the lower side of the PCM panel installation nuts located at the bottom of he cabin carpet.
- Remove four installation nuts, then pull the PCM panel down to remove from installation place.
