Contents Section: Ignition Switch/steering Lock All sections

Power Systems: Removal & Installation Mazda MPV II рестайлинг

Ignition Switch/steering Lock 18 illustrations ~287 words

ROOM FUSE INSTALLATION

Note. When the ROOM fuse is burnt or removed, the malfunction indicator lamp illuminates. If the ROOM fuse is replaced or installed with the ignition switch at ON position, the malfunction indicator lamp will continue to illuminate.

Scheme 1

Scheme 1: ROOM FUSE INSTALLATION
  1. Turn the ignition switch to LOCK position.
  2. Install the ROOM 15 A fuse.

Scheme 2

Scheme 2: FUSE BLOCK REMOVAL/INSTALLATION

Scheme 3

Scheme 3
  1. Disconnect the negative battery cable.
  2. Remove the driver-side front side trim. (See FRONT SIDE TRIM REMOVAL/INSTALLATION .)
  3. Remove in the order indicated in the figures.
  4. Install in the reverse order of removal.

Scheme 4

Scheme 4: IGNITION SWITCH REMOVAL/INSTALLATION

Scheme 5

Scheme 5
  1. Disconnect the negative battery cable.
  2. Remove the column cover.
  3. Remove in the order indicated in the figures.
  4. Install in the reverse order of removal.

Scheme 6

Scheme 6: IGNITION SWITCH INSPECTION

Scheme 7

Scheme 7
  1. Disconnect the ignition switch connectors.
  2. Inspect for continuity between the ignition switch terminals using an ohmmeter. If not as specified, replace the ignition switch.

Scheme 8

Scheme 8: KEY REMINDER SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover.
  3. Disconnect the key reminder switch connector.
  4. Remove the key reminder switch
  5. Install in the reverse order of removal.

Scheme 9

Scheme 9: KEY REMINDER SWITCH INSPECTION

Scheme 10

Scheme 10
  1. Disconnect the key reminder switch connector.
  2. Inspect for continuity between the key reminder switch terminals using an ohmmeter. If not as specified, replace the key reminder switch.

Scheme 11

Scheme 11: RELAY LOCATION

Scheme 12

Scheme 12: RELAY TYPE

Scheme 13

Scheme 13: Type A

Scheme 14

Scheme 14
  1. Remove the relay.
  2. Inspect for continuity between the relay terminals using an ohmmeter. If not as specified, replace the relay.

Scheme 15

Scheme 15: Type B

Scheme 16

Scheme 16
  1. Remove the relay.
  2. Inspect for continuity between the relay terminals using an ohmmeter. If not specified, replace the relay.

Scheme 17

Scheme 17: Type C

Scheme 18

Scheme 18
  1. Remove the relay.
  2. Inspect for continuity between the relay terminals using an ohmmeter. If not as specified, replace the relay.
