Wiring diagram: Instrument cluster — Instrument cluster circuit Mazda MPV II
All systems — 26 systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Computer data lines
- Cooling fan 2
- Cruise control
- Defoggers
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlocks
- Starting/charging 2
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 35
Click a component to highlight it on every diagram it appears on.
