B2300, B2500, B3000 & B4000 (2) Mazda MPV II

1. Measure camber and caster to determine if adjustment is necessary. If adjustment is necessary, remove upper control arm nuts and alignment plates. Install service cam and nut. (Scheme 10)
2. To increase caster, move front of upper control arm outboard and move rear of upper control arm inboard. (Scheme 11)
3. To increase camber, move front and rear of upper control arm outboard equally. (Scheme 11)
4. To decrease caster move front of upper control arm inboard and move rear of upper control arm outboard. (Scheme 11)
5. To decrease camber move front and rear of upper control arm inboard equally. NOTE: When adjusting camber/caster, adjusting lower control arm adjustment cam is not recommended.
6. On 4WD vehicles, to increase caster split, loosen lock nuts on bracket. Adjust caster set bolts forward. (Scheme 12)
7. To decrease caster split, loosen lock nuts on bracket. Adjust caster set bolts rearward. (Scheme 12)

Scheme 10

Scheme 11

Scheme 12
