TEST K: TORQUE REDUCTION (REQUEST) SIGNAL CIRCUIT FAILURE
Note. DTC C1118 (is set when torque reduction (engine condition) signal is received indicating PCM detects malfunction of torque reduction (request) signal.
TEST L: TORQUE REDUCTION (ENGINE CONDITION) SIGNAL CIRCUIT FAILURE
Note. DTC C1119 (83) is set when torque reduction (engine condition) signal is out of specification.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Brakeline Nuts | 10-16 (13-22) |
| Front Wheel Bearing Lock Nut | 174-235 (236-318) |
| Rear Wheel Bearing Lock Nut | 131-173 (177-235) |
| Stabilizer Bar-To-Lower Control Arm Nut | 32-44 (44-60) |
| Tie Rod End-To-Steering Knuckle Nut | 28-38 (38-51) |
| Wheel Lug Nuts | 66-94 (89-127) |
| Wheel Speed Sensor Mounting Bolt | 14-18 (19-25) |
| INCH Lbs. (N.m) | |
| ABS CM/Hydraulic Unit Mounting Nuts | 61-78 (7-9) |
TORQUE SPECIFICATIONS
