TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Air Cleaner Housing Bolt (626) | 12-16 (16-22) |
| Starter Mounting Bolts | 28-38 (38-51) |
| INCH Lbs. (N.m) |
| Battery Cable Nut (Solenoid Terminal "B") | 80-115 (9-13) |
| Battery Cable Nut (Solenoid Terminal "B" - MVP) | 87-104 (9.8 - 11.7) |
| Charge Air Cooler Duct Bolt (Millenia) | 70-95 (7-10) |
| Intake Air Duct Nut (626) | 71-97 (8-11) |
Starting System Wiring Diagram (Millenia). Scheme 1
Scheme 1: Starting System Wiring Diagram (Millenia)
Starting System Wiring Diagram (MPV). Scheme 2
Scheme 2: Starting System Wiring Diagram (MPV)
Starting System Wiring Diagram (MX-5 Miata). Scheme 3
Scheme 3: Starting System Wiring Diagram (MX-5 Miata)
Starting System Wiring Diagram (Protege). Scheme 4
Scheme 4: Starting System Wiring Diagram (Protege)
Starting System Wiring Diagram (626). Scheme 5
Scheme 5: Starting System Wiring Diagram (626)
