Starter - Reduction Gear: Adjustments Mazda Millenia I

Starter 1 illustration ~105 words

PINION GAP ADJUSTMENT

  1. Disconnect field lead ("M" terminal wire) at solenoid. see scheme 2 Connect positive battery lead to solenoid "S" terminal and negative battery lead to starter body. Starter pinion drive gear should extend outward and stop.
  2. Quickly measure pinion gap between end of pinion drive and circlip retainer. (Scheme 3) DO NOT operate starter solenoid for more than 10 seconds. Pinion gap should be as specified. See «PINION GAP SPECIFICATIONS»(ref-124864-S14195504102001100200000) table.
  3. If pinion gap is not within specification, adjust by increasing or decreasing thickness of solenoid shims located between solenoid and drive housing.
ApplicationIn. (mm)
Millenia0 (0)

PINION GAP SPECIFICATIONS

Scheme 3

Scheme 3
Scheme 3
