Engine Controls - Specifications - 2.5L: Other Mazda Millenia I

Specifications 3 illustrations ~174 words

ENGINE COMPRESSION

Warm engine to normal operating temperature. Remove all spark plugs. Disconnect ignition coil primary wire connector. Hold throttle plate fully open. Crank engine and note compression pressure.

ApplicationSpecification
Millenia 2.5L9.2:1

COMPRESSION RATIO

ApplicationMinimum psi (kg/cm 2 ) @ RPMStandard psi (kg/cm 2 ) @ RPM
Millenia (1)142 (10.0) @ 250203 (14.3) @ 250
(1) Difference between cylinders should not be more than 28 psi(2.0 kg/cm 2 ).
(1)Difference between cylinders should not be more than 28 psi(2.0 kg/cm 2 ).

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Application(1) In. (mm)
Millenia 2.5L(2)
(1) Adjust valves with engine cold. (2) Engines are equipped with hydraulic valve lash adjusters. Valve clearance is not adjustable.
(1)Adjust valves with engine cold.
(2)Engines are equipped with hydraulic valve lash adjusters. Valve clearance is not adjustable.

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

ApplicationPrimarySecondary
Millenia 2.5L.49-.7320,000-31,000

IGNITION COIL RESISTANCE

CRANKSHAFT POSITION SENSOR

ApplicationOhms @ 68°F (20°C)
Millenia 2.5L520-580

CRANKSHAFT POSITION SENSOR RESISTANCE

HIGH TENSION WIRE RESISTANCE

High tension wire resistance should measure 16,000 ohms per 3.28 feet (1.0M) at 68°F (20°C).

SPARK PLUGS

ApplicationNGK No.
Millenia 2.5LZFR5F-11 or ZFR6F-11

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
Millenia 2.5L.040-.043 (1.0-1.1)11-16 (15-22)

SPARK PLUG SPECIFICATIONS

Firing Order. Scheme 3

Scheme 3: Firing Order

IGNITION TIMING

ApplicationM/T(1) A/T
Millenia 2.5L (2)N/A9-11 @ 650
(1) Place automatic transmission in Park. (2) Connect a jumper wire between terminals TEN and GND of data link connector. (Scheme 4)
(1)Place automatic transmission in Park.
(2)Connect a jumper wire between terminals TEN and GND of data link connector. (Scheme 4)

IGNITION TIMING SPECIFICATIONS

Scheme 4

Scheme 4

FUEL PUMP

Note. Fuel pump performance measures fuel pressure, not regulated fuel pressure.

ApplicationPressure psi (kg/cm 2 )
Millenia 2.5L71-92 (5.0-6.5)

FUEL PUMP PERFORMANCE

ApplicationSpecification
At Idle With Vacuum30-38 psi (2.1-2.7 kg/cm 2 )
At Idle Without Vacuum38-46 psi (2.7-3.2 kg/cm 2 )

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
Millenia13.8

INJECTOR RESISTANCE

IDLE SPEED & MIXTURE

Note. Idle mixture is not adjustable. If idle mixture is incorrect, see TESTS W/CODES - 2.5L article.

Application (2)(1) RPM
Millenia600-700
(1) Place automatic transmission in Park. (2) Connect a jumper wire between terminals TEN and GND at data link connector. (Scheme 4)
(1)Place automatic transmission in Park.
(2)Connect a jumper wire between terminals TEN and GND at data link connector. (Scheme 4)

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION (TP) SENSOR

Note. For information on connector terminal identification and test conditions specified in the following tables, see ADJUSTMENTS - 2.5L article.

Condition (1)(2) Continuity Between Terminals "C" & "D"
.006" (.15 mm)Yes
.020" (.5 mm)No
(1) Insert feeler gauge of specified thickness between throttle lever and throttle stop screw. (2) (Scheme 5)
(1)Insert feeler gauge of specified thickness between throttle lever and throttle stop screw.

TP SENSOR CONTINUITY

Scheme 5

Scheme 5
ECM/PCM Wire Color (1)Closed Throttle VoltsWOT Volts
Yellow/Red (3B).1-1.02.8-4.5
(1) Measure voltage between ground and ECM/PCM terminal No. in parentheses.
(1)Measure voltage between ground and ECM/PCM terminal No. in parentheses.

TP SENSOR VOLTAGE
