Wiring diagram: Ground distribution — Ground distribution circuit Mazda CX-9 I facelift
All systems — 31 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2
- Cruise control
- Defoggers
- Engine performance 3.7l
- Exterior lights 2
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems
- Navigation 4
- Power distribution
- Power door locks 2
- Power mirrors 2
- Power seats 4
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 3
Components on these wiring diagrams 8
Click a component to highlight it on every diagram it appears on.
