Charging System [MZI-3.7]: Overview Mazda CX-9 I рестайлинг

Charging System 3 illustrations

Scheme 1

Scheme 1: CHARGING SYSTEM LOCATION INDEX [MZI-3.7]
Scheme 1: CHARGING SYSTEM LOCATION INDEX [MZI-3.7]

Scheme 2

Scheme 2: BATTERY REMOVAL/INSTALLATION [MZI-3.7]
Scheme 2: BATTERY REMOVAL/INSTALLATION [MZI-3.7]
  1. Remove in the order indicated in the table in the illustration.
  2. Install in the reverse order of removal.

Scheme 3

Scheme 3: Battery Box Installation Note
Scheme 3: Battery Box Installation Note
  1. Install the battery box so that the side with the notch points toward the front fender (LH).
