PCM CONFIGURATION [MZI-3.7]

Note. When performing the PCM configuration and PCM reprogramming simultaneously, perform the PCM configuration and then perform the PCM reprogramming after the session has been completed. If the PCM reprogramming is performed with the session not completed, it may result in improper operation of the PCM.

Scheme 43

1. Connect the M-MDS (IDS) to DLC-2.
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS (IDS). When using the IDS (laptop PC)
3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation" Select "PCM"
4. Perform the configuration according to the directions on the screen.
5. Retrieve DTCs by the M-MDS (IDS), then verify that there is no DTC present. If a DTC(s) is detected, perform the applicable DTC inspection. (See «DTC TABLE [MZI-3.7]»(ref-663050-S00956222322014101600000) .)

Open circuit

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. PSP switch terminal A and PCM terminal 1G

Short circuit

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. PSP switch terminal A and body ground

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. MAF/IAT sensor terminal A and main relay No. 1 terminal D MAF/IAT sensor terminal C and PCM terminal 1AN MAF/IAT sensor terminal D and PCM terminal 1AR MAF/IAT sensor terminal E and PCM terminal 1AT

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. MAF/IAT sensor terminal A and body ground MAF/IAT sensor terminal C and power supply MAF/IAT sensor terminal C and body ground MAF/IAT sensor terminal D and power supply MAF/IAT sensor terminal D and body ground MAF/IAT sensor terminal E and power supply

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. MAF/IAT sensor terminal B and body ground MAF/IAT sensor terminal F and PCM terminal 1P

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. MAF/IAT sensor terminal B and power supply MAF/IAT sensor terminal F and body ground MAF/IAT sensor terminal F and power supply

1. If there is no continuity, there is an open circuit. Repair or replace the wiring harness. Throttle body terminal C and PCM terminal 2AL Throttle body terminal D and PCM terminal 2AP Throttle body terminal E and PCM terminal 2Z Throttle body terminal F and PCM terminal 2AN

1. If there is continuity, there is a short circuit. Repair or replace the wiring harness. Throttle body terminal C and power supply Throttle body terminal C and body ground Throttle body terminal D and body ground Throttle body terminal E and power supply Throttle body terminal F and body ground Throttle body terminal F and power supply

1. If there is no continuity, there is an open circuit. Repair or replace the wiring harness. APP sensor terminal B and PCM terminal 1Z APP sensor terminal C and PCM terminal 1U APP sensor terminal D and PCM terminal 1AD APP sensor terminal E and PCM terminal 1AB APP sensor terminal F and PCM terminal 1Y APP sensor terminal G and PCM terminal 1X

1. If there is continuity, there is a short circuit. Repair or replace the wiring harness. APP sensor terminal A and body ground APP sensor terminal B and body ground APP sensor terminal B and power supply APP sensor terminal C and power supply APP sensor terminal D and power supply APP sensor terminal E and body ground APP sensor terminal E and power supply APP sensor terminal F and body ground

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. A/F sensor (LH) terminal C and main relay No. 1 terminal D A/F sensor (LH) terminal D and PCM terminal 2BF A/F sensor (LH) terminal E and PCM terminal 2E A/F sensor (LH) terminal F and PCM terminal 2AK A/F sensor (LH) terminal G and PCM terminal 2AO A/F sensor (LH) terminal H and PCM terminal 2AE A/F sensor (RH) terminal C and main relay No. 1 terminal D A/F sensor (RH) terminal D and PCM terminal 2BD A/F sensor (RH) terminal E and PCM terminal 2J A/F sensor (RH) terminal F and PCM terminal 2AG A/F sensor (RH) terminal G and PCM terminal 2AS A/F sensor (RH) terminal H and PCM terminal 2AC

1. If there is no continuity, the circuit is shorted. Repair or replace the wiring harness. A/F sensor (LH)/(RH) terminal C and body ground A/F sensor (LH)/(RH) terminal D and power supply A/F sensor (LH)/(RH) terminal D and body ground A/F sensor (LH)/(RH) terminal E and power supply A/F sensor (LH)/(RH) terminal F and power supply A/F sensor (LH)/(RH) terminal F and body ground A/F sensor (LH)/(RH) terminal G and power supply A/F sensor (LH)/(RH) terminal G and body ground A/F sensor (LH)/(RH) terminal H and power supply A/F sensor (LH)/(RH) terminal H and body ground

1. If there is no continuity, the circuit is open. Repair or replace the harness. HO2S (LH) terminal A and PCM terminal 3AM HO2S (LH) terminal B and PCM terminal 3AB HO2S (LH) terminal C and main relay No. 1 terminal D HO2S (LH) terminal D and PCM terminal 3X HO2S (RH) terminal A and PCM terminal 3N HO2S (RH) terminal B and PCM terminal 3Z HO2S (RH) terminal C and main relay No. 1 terminal D HO2S (RH) terminal D and PCM terminal 3X

1. If there is continuity, the circuit is shorted. Repair or replace the harness. HO2S (LH)/(RH) terminal A and power supply HO2S (LH)/(RH) terminal A and body ground HO2S (LH)/(RH) terminal B and power supply HO2S (LH)/(RH) terminal B and body ground HO2S (LH)/(RH) terminal C and body ground HO2S (LH)/(RH) terminal D and power supply

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. CKP sensor terminal B and PCM terminal 2R CKP sensor terminal A and PCM terminal 2V

1. If there is no continuity, the circuit is shorted. Repair or replace the wiring harness. CKP sensor terminal A and power supply CKP sensor terminal A and body ground CKP sensor terminal B and power supply CKP sensor terminal B and body ground

Scheme 44

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZI-3.7]»(ref-663012-S16021955892014101600000) .)
2. Remove the battery. (See «BATTERY REMOVAL/INSTALLATION [MZI-3.7]»(ref-663012-S16021955892014101600000) .)
3. Remove the following part for easier access. Remove the resonance chamber and air cleaner assembly for easier access. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZI-3.7]»(ref-663036-S20639303202014101600000) .)
4. Disconnect the CMP sensor connector
5. Remove the CMP sensor. NOTE: Lubricate the CMP O-ring seal with clean engine oil.
6. Install in the reverse order of removal.

1. CMP sensor (LH) terminal A and PCM terminal 2T
2. CMP sensor (LH) terminal B and PCM terminal 2Y
3. CMP sensor (RH) terminal A and PCM terminal 2X
4. CMP sensor (RH) terminal B and PCM terminal 2AB

1. CMP sensor (LH)/(RH) terminal A and power supply
2. CMP sensor (LH)/(RH) terminal A and body ground
3. CMP sensor (LH)/(RH) terminal B and power supply

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. KS terminal A and PCM terminal 2AH KS terminal B and PCM terminal 2AD KS terminal C and PCM terminal 2AJ KS terminal D and PCM terminal 2AF

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. KS terminal A and power supply KS terminal A and body ground KS terminal B and power supply KS terminal B and body ground KS terminal C and power supply KS terminal C and body ground KS terminal D and power supply KS terminal D and body ground

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. CHT sensor terminal A and PCM terminal 2AV CHT sensor terminal B and PCM terminal 2G

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. CHT sensor terminal A and power supply CHT sensor terminal A and body ground CHT sensor terminal B and body ground

1. If there is no continuity, the circuit is open. Repair or replace the wiring harness. Fuel tank pressure sensor terminal A and PCM terminal 1D Fuel tank pressure sensor terminal B and PCM terminal 1AT Fuel tank pressure sensor terminal C and PCM terminal 1I

1. If there is continuity, the circuit is shorted. Repair or replace the wiring harness. Fuel tank pressure sensor terminal A and body ground Fuel tank pressure sensor terminal B and power supply Fuel tank pressure sensor terminal C and power supply Fuel tank pressure sensor terminal C and body ground
