Dynamic Stability Control/roll Stability Control: Other Mazda CX-9 I рестайлинг

Preparation

1. Verify that battery is fully charged.
2. Turn the ignition switch to the ON position, and verify that the ABS warning light goes out after approx. 3 s.
3. Turn the ignition switch off.
4. Jack up the vehicle and support it evenly on safety stands.
5. Shift to the N position.
6. Verify that all four wheels rotate.
7. Rotate the inspected wheels by hand, and verify there is no brake drag. If there is any brake drag, perform regular brake inspection. If there is no brake drag, perform DSC/RSC HU/CM operation inspection.

Scheme 24

1. Perform "Preparation".
2. Connect the M-MDS to the DLC-2.
3. Set up an active command mode inspection according to the combination of commands below. Brake pressure retention WHEELS INSPECTION CHART Command name Inspected wheels LF RF LR RR V_TRC_L OFF V_TRC_R V_STB_L V_STB_R V_LF_INL ON OFF OFF OFF V_LF_OTL OFF V_LR_INL ON V_LR_OTL OFF V_RF_INL ON V_RF_OTL OFF V_RR_INL ON V_RR_OTL OFF PMP_MOTOR OFF Brake pressure reduction WHEELS INSPECTION CHART Command name Inspected wheels LF RF LR RR V_TRC_L OFF V_TRC_R V_STB_L V_STB_R V_LF_INL ON OFF OFF OFF V_LF_OTL V_LR_INL OFF ON V_LR_OTL V_RF_INL ON OFF V_RF_OTL V_RR_INL OFF ON V_RR_OTL PMP_MOTOR ON CAUTION: To protect the DSC/RSC HU/CM, the solenoid valve and the pump motor used during active command mode stay on for only 10 s or less each time they are switched on. NOTE: When working with two people, one should press on the brake pedal, and the other should attempt to rotate the wheel being inspected.
4. Send the command while depressing on the brake pedal and attempting to rotate the wheel being inspected.
5. While brake pressure is maintained and a DSC/RSC HU/CM operation click sound is heard, confirm that the wheel does not rotate. While brake pressure is being reduced and an DSC/RSC HU/CM operation click sound is heard, confirm that the wheel rotates. Performing the inspection above determines the following: The DSC/RSC HU/CM brake lines are normal. The DSC/RSC HU/CM hydraulic system is not significantly abnormal (including DSC/RSC HU/CM). The DSC/RSC HU/CM internal electrical parts (solenoid, motor and other parts) are normal. The DSC/RSC unit and DSC/RSC HU/CM output system wiring harnesses (solenoid valve, relay system) are normal. However, the following items cannot be verified. Malfunction with intermittent occurrence of the above items Malfunction of DSC/RSC HU/CM input system wiring harnesses and parts Extremely small leaks in the DSC/RSC HU/CM internal hydraulic system

DSC/RSC HU AIR BLEEDING

1. Turn the ignition switch to the LOCK position.
2. Connect the M-MDS (IDS) to the DLC-2.
3. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. Select "Chassis". Select "Braking".
4. Then, select items from the screen menu in the following order. Select "ABS Service Bleed"
5. Perform the air bleeding according to the directions on the screen.

DSC/RSC SENSOR INITIALIZATION PROCEDURE

1. Inspect the wheel alignment and inflation pressure. If there is any malfunction, adjust the applicable part.
2. Park the vehicle on level ground.
3. Turn the ignition switch to the LOCK position.
4. Connect the M-MDS to the DLC-2.
5. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Chassis". Select "ABS/DSC". Select "Sensor Initialization".
6. Perform the initialization according to the directions on the screen.
