Scheme 1

Scheme 1: WIPER/WASHER SYSTEM LOCATION INDEX

Scheme 2

Scheme 2: WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION
  1. Remove in the order indicated in the table.
  2. Install in the reverse order of removal.
  3. Adjust the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE ADJUSTMENT»(ref-375374-S40327878592010102800000) .)

Scheme 3

Scheme 3: Windshield Wiper Arm Installation Note
  1. Clean the windshield wiper arm connector shafts using a wire brush before installing the windshield wiper arms.

Scheme 4

Scheme 4: WINDSHIELD WIPER ARM AND BLADE ADJUSTMENT

Scheme 5

Scheme 5
  1. Operate the windshield wipers, and then turn off the windshield wiper motor to set the wipers in the park position.
  2. Slide the serrated connecting part and adjust the windshield wiper arm and blade so that its end is aligned with the hollowed mark in the ceramic coating. NOTE: If the hollowed mark in the ceramic coating cannot be located, measure the distance from the cowl grille end line, and adjust the windshield wiper arm and blade.

Scheme 6

Scheme 6: WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-375374-S11692705452010102800000) .)
  3. Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-375375-S07009167252010102800000) .)
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 7

Scheme 7: WINDSHIELD WIPER MOTOR INSPECTION
  1. Disconnect the windshield wiper motor connector.
  2. Connect battery positive voltage to windshield wiper motor terminal D or E, and ground to terminal B, then verify that the windshield wipers operate as shown in the table. If the windshield wipers do not operate as indicated in the table, replace the windshield wiper motor. WINDSHIELD WIPER MOTOR OPERATION CONDITION CHART Terminal connected to battery positive voltage Operation condition D LO E HI
  3. Disconnect battery positive voltage from the motor terminal D while the wipers are operating.
  4. Verify that the wipers do not stop in the park position.
  5. Short between the motor terminals D and C, and connect battery positive voltage to the motor terminal A.
  6. Verify that the wipers operate at low speed again, then stop in the park position. If there is any malfunction, replace the windshield wiper motor.

Scheme 8

Scheme 8: WASHER TANK REMOVAL/INSTALLATION

Scheme 9

Scheme 9
  1. Disconnect the negative battery cable.
  2. Remove the mudguard (RH). (Vehicles without washer fluid-level sensor)
  3. Remove the front bumper. (Vehicles with washer fluid-level sensor) (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-375392-S25264795932010102800000) .)
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 10

Scheme 10: WINDSHIELD WASHER MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the mudguard (RH).
  3. Disconnect the connector.
  4. Disconnect the windshield washer hose.
  5. Remove the windshield washer motor, then remove the grommet.
  6. Install in the reverse order of removal.

Scheme 11

Scheme 11: WINDSHIELD WASHER MOTOR INSPECTION
  1. Connect battery positive voltage to windshield washer motor terminal A and terminal B to ground.
  2. Verify that the windshield washer motor operates normally. If there is any malfunction, replace the windshield washer motor.

Scheme 12

Scheme 12: WINDSHIELD WASHER NOZZLE REMOVAL/INSTALLATION
  1. Remove the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-375374-S11692705452010102800000) .)
  2. Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-375375-S07009167252010102800000) .)
  3. Remove the windshield washer hose from the windshield washer nozzle.
  4. Squeeze the tabs of the windshield washer nozzle.
  5. Pull the windshield washer nozzle out to remove it.
  6. Install in the reverse order of removal.

Scheme 13

Scheme 13: WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION

Scheme 14

Scheme 14
  1. Remove the mudguard (RH).
  2. Disconnect windshield washer hose A from the windshield washer motor.
  3. Remove windshield washer hose A from clip A.
  4. Disconnect joint pipe A and remove windshield washer hose A, B.
  5. Remove the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-375374-S11692705452010102800000) .)
  6. Remove the cowl grill. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-375375-S07009167252010102800000) .)
  7. Remove windshield washer hose B from hook.
  8. Disconnect windshield washer hose C from the washer nozzle.
  9. Disconnect windshield washer hose D from the washer nozzle.
  10. Disconnect joint pipe B and remove windshield washer hose C, B and D.
  11. Install in the reverse order of removal.

Scheme 15

Scheme 15: REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION
  1. Remove in the order indicated in the table.
  2. Install in the reverse order of removal.
  3. Adjust the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE ADJUSTMENT»(ref-375374-S40513490942010102800000) .)

Scheme 16

Scheme 16: Rear Wiper Arm Installation Note
  1. Clean the rear wiper arm connector shaft using a wire brush before installing the rear wiper arm.

Scheme 17

Scheme 17: REAR WIPER ARM AND BLADE ADJUSTMENT
  1. Turn off the rear wiper switch while operating the rear wiper motor, and then stop the rear wiper at the auto-stop position.
  2. Set the rear wiper arm onto the ceramic end line.

Scheme 18

Scheme 18: REAR WIPER MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-375374-S33871911772010102800000) .)
  3. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) .)
  4. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05467767222010102800000) .)
  5. Remove the liftgate lower trim. (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S12242040212010102800000) .)
  6. Remove in the order indicated in the table.
  7. Install in the reverse order of removal.

Scheme 19

Scheme 19: REAR WIPER MOTOR INSPECTION
  1. Connect battery positive voltage to the rear wiper motor terminal A, and ground the rear wiper motor terminal B.
  2. Verify that the rear wiper motor operates. If there is any malfunction, replace the rear wiper motor.

Scheme 20

Scheme 20: REAR WASHER MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the mudguard (RH).
  3. Disconnect the connector.
  4. Disconnect the rear washer hose.
  5. Remove the rear washer motor, then remove the grommet.
  6. Install in the reverse order of removal.

Scheme 21

Scheme 21: REAR WASHER MOTOR INSPECTION
  1. Connect battery positive voltage to rear washer motor terminal A and terminal B to ground.
  2. Verify that the rear washer motor operates normally. If there is any malfunction, replace the rear washer motor.

Scheme 22

Scheme 22: REAR WASHER NOZZLE REMOVAL/INSTALLATION
  1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) .)
  2. Remove the rear spoiler. (See «REAR SPOILER REMOVAL/INSTALLATION»(ref-375375-S30057224012010102800000) .)
  3. Press the tabs and remove the rear washer nozzle.
  4. Install in the reverse order of removal.
  5. Adjust the rear washer nozzle. (See «REAR WASHER NOZZLE ADJUSTMENT»(ref-375374-S26184651392010102800000) .)

Scheme 23

Scheme 23: REAR WASHER NOZZLE ADJUSTMENT
  1. Insert a needle or an equivalent tool into the spray hole of the rear washer nozzle and adjust the nozzle direction as shown.

Scheme 24

Scheme 24: REAR WASHER HOSE REMOVAL/INSTALLATION

Scheme 25

Scheme 25
  1. Disconnect the negative battery cable.
  2. Remove the mudguard (RH).
  3. Disconnect rear washer hose A from the washer tank.
  4. Remove rear washer hose A from clip A.
  5. Disconnect joint pipe A and remove rear washer hose A.
  6. Remove the following parts: Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Dashboard under cover Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-375369-S34089285102010102800000) .) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]»(ref-375367-S26882181632010102800000) .) (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]»(ref-375367-S08977046652010102800000) .) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-375422-S40455233162010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-375320-S24848646192010102800000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-375422-S10719057362010102800000) .)
  7. Disconnect joint pipe B and remove rear washer hose B.
  8. Disconnect joint pipe C and remove rear washer hose C.
  9. Remove rear washer hose C from clips B.
  10. Disconnect joint pipe D and remove rear washer hose C.
  11. Detach clips B.
  12. Remove the following parts: Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .)
  13. Disconnect joint pipe E.
  14. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-375422-S31648295792010102800000) .)
  15. Remove rear washer hose D from clips C and D.
  16. Cut the urethane of the headliner and remove the tape and rear washer hose D. NOTE: After installing the rear washer hose, reinforce the urethane that was cut when removing.
  17. Remove rear washer hose E from the rear washer nozzle.
  18. Install in the reverse order of removal.

Scheme 26

Scheme 26: WIPER AND WASHER SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .)
  3. Disconnect the wiper and washer switch connector.
  4. Remove the screws, then remove the wiper and washer switch.
  5. Install in the reverse order of removal.

Scheme 27

Scheme 27: Vehicles Without Auto Wiper System

Scheme 28

Scheme 28
  1. Verify that the continuity between the windshield wiper and washer switch is as indicated in the table. Verify that the continuity between the windshield wiper and washer switch is as indicated in the table.

Scheme 29

Scheme 29: Vehicles With Auto Wiper System

Scheme 30

Scheme 30
  1. Verify that the continuity between the windshield wiper and washer switch is as indicated in the table. Verify that the continuity between the windshield wiper and washer switch is as indicated in the table.

Scheme 31

Scheme 31: REAR WIPER AND WASHER SWITCH INSPECTION

Scheme 32

Scheme 32
  1. Verify that the continuity between the rear wiper and washer switch terminals is as indicated in the table. If not as indicated in the table, replace the wiper and washer switch.

Scheme 33

Scheme 33: WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the washer tank. (See «WASHER TANK REMOVAL/INSTALLATION»(ref-375374-S12173154632010102800000) .)
  3. Disconnect the connector.
  4. Remove the washer fluid-level sensor.
  5. Remove the grommet.
  6. Install in the reverse order of removal.

Scheme 34

Scheme 34: WASHER FLUID-LEVEL SENSOR INSPECTION

Scheme 35

Scheme 35
  1. Disconnect the negative battery cable.
  2. Inspect for continuity between the washer fluid-level sensor terminals using an ohmmeter. If not as specified, replace the washer fluid-level sensor.
