STARTER REMOVAL/INSTALLATION [L5]
| WARNING | Remove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. When the battery cables are connected, touching the vehicle body with starter terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the negative battery cable before performing the following operation. |
Scheme 37
- Disconnect the negative battery cable.
- Remove the plug hole plate. (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [L5]»(ref-375350-S23041993352010102800000) .)
- Remove the air hose, air cleaner and fresh air duct component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [L5]»(ref-375352-S14647925242010102800000) .)
- Disconnect the manifold absolute pressure (MAP) sensor connector. (See «MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR REMOVAL/INSTALLATION [L5]»(ref-375347-S05476796052010102800000) .)
- Remove the under cover.
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 38
- Remove the starter from above the engine compartment.
Starter Installation Note
Note. If there is peeling on or damage to the insulator, attach a new insulator using the following procedure
Scheme 39
Scheme 40
Scheme 41
- Peel off the insulator from the starter completely using a scraper.
- Degrease the insulator attachment area.
- Attach a new insulator to the starter.
