General Information: Other Mazda CX-7 I рестайлинг

Range of Topics

1. This manual contains procedures for performing all required service operations. The procedures are divided into the following five basic operations: Removal/Installation Disassembly/Assembly Replacement Inspection Adjustment
2. Simple operations which can be performed easily just by looking at the vehicle (i.e., removal/installation of parts, jacking, vehicle lifting, cleaning of parts, and visual inspection) have been omitted.

Symbols

1. There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST or equivalent, use. These symbols show application points or use of these materials during service.

Scheme 22

Advisory Messages

1. You will find several Warnings, Cautions, Notes, Specifications and Upper and Lower Limits in this manual.

Note. A Note provides added information that will help you to complete a particular procedure.

Specification

1. The values indicate the allowable range when performing inspections or adjustments.

Upper and lower limits

1. The values indicate the upper and lower limits that must not be exceeded when performing inspections or adjustments.

Scheme 23

UNITS

UNITS CHART

Conversion to SI Units (Systeme International d'Unites)

1. All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted from these values.

Rounding Off

1. Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.

Upper and Lower Limits

1. When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI unit value may differ after conversion. For example, consider 2.7 kgf/cm 2 in the following specifications: 210-260 kPa {2.1-2.7 kgf/cm 2 , 30-38 psi} 270-310 kPa {2.7-3.2 kgf/cm 2 , 39-45 psi}
2. The actual converted values for 2.7 kgf/cm 2 are 264 kPa and 38.4 psi. In the first specification, 2.7 is used as an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is used as a lower limit, so the converted values are rounded up to 270 and 39.

Injury/damage Prevention Precautions

1. Depending on the vehicle, the cooling fan may operate suddenly even when the ignition switch is turned off. Therefore, keep hands and tools away from the cooling fan even if the cooling fan is not operating to prevent injury to personnel or damage to the cooling fan. Always disconnect the negative battery cable when servicing the cooling fan or parts near the cooling fan.

Protection of the Vehicle

1. Always be sure to cover fenders, seats and floor areas before starting work.

Scheme 24

Preparation of Tools and Measuring Equipment

1. Be sure that all necessary tools and measuring equipment are available before starting any work.

Scheme 25

Special Service Tools

1. Use special service tools or the equivalent when they are required.

Scheme 26

Negative battery cable disconnection/connection

1. Perform the following system initialization after disconnecting the negative battery cable.

NEGATIVE BATTERY CABLE REFERENCE CHART

Required procedure following negative battery cable disconnection

NEGATIVE BATTERY CABLE DISCONNECTION PROCEDURE REFERENCE

Using UV light (black light)

1. Remove any oil on the engine or transaxle/transmission. NOTE: Referring to the fluorescent dye instruction manual, mix the specified amount of dye into the engine oil or ATF (or transaxle/transmission oil).
2. Pour the fluorescent dye into the engine oil or ATF (or transaxle/transmission oil).
3. Allow the engine to run for 30 min.
4. Inspect for dye leakage by irradiating with UV light (black light), and identify the type of oil that is leaking.
5. If no dye leakage is found, allow the engine to run for another 30 min. or drive the vehicle then reinspect.
6. Find where the oil is leaking from, then make necessary repairs. NOTE: To determine whether it is necessary to replace the oil after adding the fluorescent dye, refer to the fluorescent dye instruction manual.

Not using UV light (black light)

1. Gather some of the leaking oil using an absorbent white tissue.
2. Take samples of engine oil and ATF (or transaxle/transmission oil), both from the dipstick, and place them next to the leaked oil already on the tissue.
3. Compare the appearance and smell, and identify the type of oil that is leaking.
4. Remove any oil on the engine or transaxle/transmission.
5. Allow the engine to run for 30 min.
6. Check the area where the oil is leaking, then make necessary repairs.

Scheme 27

Arrangement of Parts

1. All disassembled parts should be carefully arranged for reassembly.
2. Be sure to separate or otherwise identify the parts to be replaced from those that will be reused.

Scheme 28

Cleaning of Parts

1. All parts to be reused should be carefully and thoroughly cleaned in the appropriate method.

Scheme 29

Scheme 30

Scheme 31

1. Standard values, such as torques and certain adjustments, must be strictly observed in the reassembly of all parts.
2. If removed, these parts should be replaced with new ones: Oil seals Gaskets O-rings Lock washers Cotter pins Nylon nuts
3. Depending on location: Sealant and gaskets, or both, should be applied to specified locations. When sealant is applied, parts should be installed before sealant hardens to prevent leakage. Oil should be applied to the moving components of parts. Specified oil or grease should be applied at the prescribed locations (such as oil seals) before reassembly.

Rubber Parts and Tubing

1. Prevent gasoline or oil from getting on rubber parts or tubing.

Scheme 32

Hose Clamps

1. When reinstalling, position the hose clamp in the original location on the hose and squeeze the clamp lightly with large pliers to ensure a good fit.

Scheme 33

Vise

1. When using a vise, put protective plates in the jaws of the vise to prevent damage to parts.

Scheme 34

Dynamometer

1. When inspecting and servicing the power train on the dynamometer or speedometer tester, pay attention to the following: Place a fan, preferably a vehicle-speed proportional type, in front of the vehicle. Make sure the vehicle is in a facility with an exhaust gas ventilation system. Since the rear bumper might deform from the heat, cool the rear with a fan. (Surface of the bumper must be below 70°C {158°F}.) Keep the area around the vehicle uncluttered so that heat does not build up. Watch the water temperature gauge and do not overheat the engine. Avoid added load to the engine and maintain normal driving conditions as much as possible. NOTE: When only the front or rear wheels are rotated on a chassis dynamometer or equivalent, the DSC HU/CM determines that there is a malfunction in the DSC and illuminates the following lights: ABS warning light Brake system warning light DSC indicator light If the above lights are illuminated, dismount the vehicle from the chassis dynamometer and turn the ignition switch to the LOCK position. Then, turn the ignition switch back to the ON position, run the vehicle at 10 km/h or more and verify that the warning lights go out. In this case, a DTC will be stored in the memory. Clear the DTC from the memory by following the memory clearing procedure [DSC] in the onboard diagnostic system. (See «ON-BOARD DIAGNOSIS»(ref-375322-S24289626392010102800000) .)

Speedometer tester measurement

Free roller type

1. Align the free rollers with the wheel base and tread, then set them on the floor properly.
2. Drive the vehicle slowly onto the tester roller and free rollers.
3. Start the engine and accelerate gradually to inspect the speedometer.
4. After inspection, decelerate gradually with gentle braking.

Scheme 35

Scheme 36

1. Remove the propeller shaft. (See «PROPELLER SHAFT REMOVAL/INSTALLATION»(ref-375323-S20053156452010102800000) .)
2. Place the front wheels on the tester roller.
3. Accelerate gradually and inspect the speedometer.
4. After inspection, decelerate gradually with gentle braking.
5. Install the propeller shaft. (See «PROPELLER SHAFT REMOVAL/INSTALLATION»(ref-375323-S20053156452010102800000) .)

Scheme 37

1. Place the wheels (front or rear) to be measured on the tester roller.
2. Shift to the N position/neutral.
3. Activate the tester roller and measure braking force. If there is a large amount of brake drag force, the electronic control system coupling may be affected. Jack up all four wheels to eliminate the effect of the coupling and rotate each wheel by hand to verify the rotation condition.

Wheel balancer (on the vehicle balancer)

1. Jack up all four wheels.
2. Support the wheels (front or rear) on the side to be measured (near the wheels) using a wheel balancer sensor stand.
3. Support the wheels on the side not to be measured (near the wheels) using safety stands.
4. Set up the wheel balancer and rotate the wheels using engine drive to measure the wheel balance.

Scheme 38

Scheme 39

Scheme 40

1. Some global SST or equivalent are used as SSTs necessary for vehicle repair. Note that these SSTs are marked with global SST numbers.
2. Note that a global SST number is written together with a corresponding Mazda SST number as shown below. Example (section **-60) Example (Except section **-60)

Battery cable

1. Before disconnecting connectors or removing electrical parts, disconnect the negative battery cable.

Scheme 41

Scheme 42

Scheme 43

1. To remove the wiring harness from the clip in the engine room, pry up the hook of the clip using a flathead screwdriver. CAUTION: Do not remove the wiring harness protective tape. Otherwise, the wires could rub against the body, which could result in water penetration and electrical shorting.

Disconnecting connectors

1. When disconnecting a connector, grasp the connectors, not the wires.

Scheme 44

1. Connectors can be disconnected by pressing or pulling the lock lever as shown.

Scheme 45

Locking connector

1. When locking connectors, listen for a click indicating they are securely locked.

Scheme 46

Sensors, Switches, and Relays

1. Handle sensors, switches, and relays carefully. Do not drop them or strike them against other objects.

Scheme 47

Viewing orientation for Connectors

1. The viewing orientation for connectors is indicated with a symbol.
2. The figures showing the viewing orientation are the same as those used in Wiring Diagrams.
3. The viewing orientations are shown in the following three ways.

Part-side connector

The viewing orientation for part-side connectors is from the terminal side.

* : Part names are shown only when there are multiple connector drawings.

Scheme 48

Other

When it is necessary to show the terminal side of the vehicle wiring harness-side connectors, such as the following connectors, the viewing orientation is from the terminal side.

1. Main fuse block and the main fuse block relays
2. Data link connector
3. Check connector
4. Relay box

Scheme 49

Jumper wire

1. A jumper wire is used to create a temporary circuit. Connect the jumper wire between the terminals of a circuit to bypass a switch.

Scheme 50

Voltmeter

1. The DC voltmeter is used to measure circuit voltage. A voltmeter with a range of 15 V or more is used by connecting the positive (+) probe (red lead wire) to the point where voltage will be measured and the negative (-) probe (black lead wire) to a body ground.

Scheme 51

Ohmmeter

1. The ohmmeter is used to measure the resistance between two points in a circuit and to inspect for continuity and short circuits.

Scheme 52

Precautions Before Welding

A vehicle has various electrical parts. To protect the parts from excessive current generated when welding, be sure to perform the following procedure.

Scheme 53

Scheme 54

1. Turn the ignition switch to the LOCK position.
2. Disconnect the battery cables.
3. Securely connect the welding machine ground near the welding area.
4. Cover the peripheral parts of the welding area to protect them from weld spatter.

Jacking Positions

1. Use safety stands to support the vehicle after it has been lifted.

Front

Note. To prevent obstruction between the jack body and front bumper when the jack body is inserted, use a low-floor type jack Near the center or the front crossmember.

Scheme 55

2WD

1. Near the center of the rear crossmember.

Scheme 56

AWD

1. At the center of the rear differential.

Scheme 57

Vehicle Lift Positions, Safety Stand Positions

Note. The arrow at the rear of the vehicle indicates that it is the same as the illustration for the front of the vehicle. Both sides of the vehicle, on side sills.

Scheme 58

Rear

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Proper lifting and towing are necessary to prevent damage to the vehicle. Particularly when towing a AWD vehicle, where all the wheels are connected to the drive train, proper transporting of the vehicle is absolutely essential to avoid damaging the drive system. Government and local laws must be followed.
2. A towed 2WD vehicle should have its drive wheels (front wheels) off the ground. If excessive damage or other conditions prevent this, use wheel dollies.
3. When towing a 2WD vehicle with the rear wheels on the ground, release the parking brake.
4. A towed AWD vehicle must have all its wheels off the ground. CAUTION: Don't tow the vehicle pointed backward with driving wheels on the ground. This may cause internal damage to the transaxle. CAUTION: Don't tow with sling-type equipment. This could damage the vehicle. Use wheel-lift or flatbed equipment. WARNING: Towing a AWD vehicle with either the front or rear wheels on the ground is dangerous as the drive train could be damaged, or the vehicle could trail away from the tow truck and cause an accident. If the drive train has been damaged, transport the vehicle on a flat bed truck.

Vehicle Securing Position

Scheme 64

Scheme 65

Scheme 66

Note. The tiedown eyelet is used only when the vehicle is transported by ship.

Scheme 67

Scheme 68

Scheme 69

SAE STANDARDS

1. In accordance with new regulations, SAE (Society of Automotive Engineers) standard names and abbreviations are now used in this manual. The table below lists the names and abbreviations that have been used in Mazda manuals up to now and their SAE equivalents.

SAE STANDARDS

Schedule 1 (Normal Driving Conditions) for USA

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

MAINTENANCE CHART

Schedule 2 CANADA, Puerto Rico, and (Unique Driving Conditions) for USA

1. Repeated short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates
8. Driving in extremely hot conditions
9. Driving in mountainous conditions continually

MAINTENANCE CHART

Schedule 1 (Normal Driving Conditions) for Mexico

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

MAINTENANCE CHART

Schedule 2 (Unique Driving Conditions) for Mexico

1. Repeated short-distance driving
2. Driving in dusty conditions
3. Driving with extended use of brakes
4. Driving in areas where salt or other corrosive materials are used
5. Driving on rough or muddy roads
6. Extended periods of idling or low-speed operation
7. Driving for long periods in cold temperatures or extremely humid climates
8. Driving in extremely hot conditions
9. Driving in mountainous conditions continually

MAINTENANCE CHART
