Interior Trim: Removal & Installation Mazda CX-7 I рестайлинг

Dashboard Removal Note

1. Take the dashboard out through the opened front driver-side door.

Scheme 36

1. Disconnect the connector by pulling it in direction (2) while pressing the tab in direction (1).

Scheme 37

1. Pull the dashboard upper garnish outward and detach clips A.
2. Remove the dashboard upper garnish.
3. Install in the reverse order of removal.

Scheme 38

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 39

1. Remove the following parts: Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S14019315092010102800000) .). Dashboard upper garnish (See «DASHBOARD UPPER GARNISH REMOVAL/INSTALLATION»(ref-375422-S31128084802010102800000) .) Multi information display (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-375337-S00486604342010102800000) .) Front speaker (See «FRONT SPEAKER REMOVAL/INSTALLATION»(ref-375342-S34707649062010102800000) .) Center speaker cover (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-375342-S12608237582010102800000) .) Center speaker (See «CENTER SPEAKER REMOVAL/INSTALLATION»(ref-375342-S12608237582010102800000) .) Microphone (See «MICROPHONE REMOVAL/INSTALLATION»(ref-375342-S36116827502010102800000) .) Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 40

1. Remove the screws.
2. Pull the upper column cover upward and detach the upper column cover from the lower column cover. NOTE: The upper column cover is integrated with the meter hood.
3. Remove the lower column cover.
4. Remove the ignition key illumination.
5. Install in the reverse order of removal.

Scheme 41

1. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) )
2. Remove the screws.
3. Pull the center panel while remove the clips A.
4. Remove the center panel.
5. Disconnect the center speaker connector. (Vehicles with Bose®)
6. Disconnect the microphone connector. (Vehicles with Bluetooth system)
7. Install in the reverse order of removal.

Scheme 42

1. Remove the following parts: Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .)
2. Remove the screws.
3. Pull the lower panel outward and detach clips A.
4. Remove the passenger compartment temperature sensor. (See «PASSENGER COMPARTMENT TEMPERATURE SENSOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-375369-S24043052122010102800000) .)
5. Disconnect the headlight leveling switch connector and TCS OFF switch connector.
6. Remove the lower panel.
7. Install in the reverse order of removal.

Scheme 43

1. Remove the following parts: Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .)
2. Remove the screws.
3. Pull the lower panel outward and detach clips A.
4. Remove the lower panel.
5. Install in the reverse order of removal.

Scheme 44

1. Remove the following parts: Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .)
2. Pull the upper column cover upward and detach the upper column cover from the lower column cover.
3. Pull the meter hood and remove clips A and tabs B.
4. Remove the meter hood.
5. Install in the reverse order of removal.

Scheme 45

1. Press the stay damper in the direction shown by the arrow and detach it from the glove compartment lid.
2. Bend the stoppers inward to remove.
3. Turn the glove compartment downward and pull the pins.
4. Remove the glove compartment.
5. Install in the reverse order of removal.

VENTILATOR GRILLE REMOVAL/INSTALLATION

Scheme 46

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (driver's side) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (driver's side) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Dash board garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-375422-S40302664672010102800000) .)
3. Remove the screws.
4. Remove the ventilator grille.
5. Remove the tab A.
6. Remove the demister grille.
7. Install in the reverse order of removal.

Scheme 47

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (passenger's side) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (passenger's side) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Grove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-375422-S25337417152010102800000) .) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .)
3. Remove the screws A.
4. Remove the bracket.
5. Remove the screws B.
6. Remove the ventilator grille.
7. Remove the tab C.
8. Remove the demister grille.
9. Install in the reverse order of removal.

Scheme 48

1. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) )
2. Remove the center panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) )
3. Remove the screws.
4. Remove the ventilator grille.
5. Install in the reverse order of removal.

Scheme 49

1. Remove the following parts: Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (driver's side) (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .)
2. Remove the bolts.
3. Remove the knee bolster.
4. Install in the reverse order of removal.

Scheme 50

1. Pull the sail garnish outward and detach clips A and B.
2. Remove the sail garnish.
3. Install in the reverse order of removal.

Scheme 51

1. Remove the fastener.
2. Detach hooks A and guide B by pulling it in the direction of the arrow.
3. Remove the dashboard under cover.
4. Install in the reverse order of removal.

Scheme 52

1. Detach hooks A and guide B by pulling it in the direction of the arrow.
2. Remove the dashboard under cover.
3. Install in the reverse order of removal.

Scheme 53

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar lower trim (driver's side) (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (driver's side) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .)
3. Remove the screws.
4. Pull the dashboard garnish outward and detach clips A.
5. Install in the reverse order of removal.

Scheme 54

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .)
3. Pull the panel upward and detach clips A, B and tabs C.
4. Disconnect the accessory socket connector.
5. Disconnect the seat warmer switch connectors. (vehicles with seat warmer system)
6. Remove the panel.
7. Remove the covers.
8. Remove the fasteners and screws.
9. Remove the pins A.
10. Remove the console.
11. Install in the reverse order of removal.

Scheme 56

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 57

1. Detach clips A by pulling them in the direction of the arrow.
2. Remove the decoration panel.
3. Install in the reverse order of removal.

Scheme 58

Scheme 59

1. Remove clips A in order starting from the vehicle rear using a tape-wrapped flathead screwdriver.
2. Remove the parts in the order of pin B, clip C and tab D from the vehicle rear.
3. Remove the pin E.
4. Remove the console panel.
5. Install in the reverse order of removal.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Remove the A-pillar lower trim. (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) )
2. Partially peel back the seaming welt.
3. Pull the A-pillar trim shown in the figure in the direction of the arrow, raise clip B from its grommet together with the A-pillar trim, and remove clips A at the same time.
4. Slide the A-pillar trim in the direction of the arrow shown in the figure and remove the A-pillar trim from clip B.
5. Rotate and pull clip B in the direction of the arrow shown in the figure until it is no longer loose, and feels tight.
6. Pull clip B and remove it from the grommet.
7. Insert a tape-wrapped flathead screwdriver between the body and the grommet.
8. Press the tabs and remove the grommet.
9. Install the new grommet to the body.
10. Install the new clip B to the A-pillar trim.
11. Install the A-pillar trim.

Scheme 64

1. Pull the A-pillar lower trim upward and detach clips A from the dashboard.
2. Pull the A-pillar lower trim outward and detach clips B and tab C.
3. Remove the A-pillar lower trim.
4. Install in the reverse order of removal.

Scheme 65

1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .)
2. Partially peel back the seaming welt.
3. Remove the nut.
4. Pull the front side trim in the direction shown by the arrow, then detach clip A.
5. Remove the front side trim.
6. Install in the reverse order of removal.

Scheme 66

1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .)
2. Remove the rear scuff plate inner. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .)
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim outward and detach clips A, C and locator pins B.
5. Remove the B-pillar lower trim.
6. Install in the reverse order of removal.

Scheme 67

Scheme 68

1. Remove the following parts: Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .)
2. Partially peel back the seaming welt.
3. Remove the screw.
4. Pull the B-pillar upper trim outward and detach clip A and locator pin B.
5. Pull the B-pillar upper trim downward and detach the tabs and clip C.
6. Remove the B-pillar upper trim.
7. Turn the clip installed on the body 90° in the direction indicated by the arrow in the figure and pull them out.
8. Remove clip C from the body, then install it to the B-pillar upper trim.
9. Install in the reverse order of removal.

Scheme 69

Scheme 70

1. Remove the following parts: Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .)
2. Partially peel back the seaming welt.
3. Remove the screw.
4. Pull the C-pillar trim outward and detach clip A and pins B, C.
5. Pull the C-pillar upper trim downward and detach the tabs and clip D.
6. Remove the C-pillar trim.
7. Turn the clip installed on the body 90° in the direction indicated by the arrow in the figure and pull them out.
8. Remove clip D from the body, then install it to the C-pillar trim.
9. Install in the reverse order of removal.

Scheme 71

1. Remove the following parts: Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .)
2. Partially peel back the seaming welt.
3. Remove the fastener.
4. Pull the D-pillar trim outward and detach clips A and pin B.
5. Pull the D-pillar trim upward and detach hook C.
6. Remove the D-pillar trim.
7. Install in the reverse order of removal.

Scheme 72

1. Pull the front scuff plate inner upward while detaching tabs A, detach clips B, pins C and tab D from the body, and then remove the front scuff plate inner.
2. Install in the reverse order of removal.

Scheme 73

1. Pull the front scuff plate outer upward, detach clips A, pins B and C from the body, and then remove the front scuff plate outer.
2. Install in the reverse order of removal.

Scheme 74

1. Pull the rear scuff plate inner upward while detaching tabs A and B, detach clips C, pins D from the body, and then remove the rear scuff plate inner.
2. Install in the reverse order of removal.

Scheme 75

1. Pull the rear scuff plate outer upward, detach clips A, pins B and C from the body, and then remove the rear scuff plate outer.
2. Install in the reverse order of removal.

Scheme 76

1. Pull the inner garnish outward and detach clips A.
2. Remove the hook B.
3. Remove the inner garnish.
4. Install in the reverse order of removal.

Scheme 77

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 78

1. Remove the sub trunk box. (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) )
2. Remove the fasteners.
3. Pull the trunk end trim upward, then disengage tabs A, clips B and pins C.
4. Remove the tabs D.
5. Remove the trunk end trim.
6. Remove the bezel.
7. Install in the reverse order of removal.

Scheme 79

Scheme 80

1. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .)
2. Remove the screw.
3. Pull the remote handle lever outward and detach clip A.
4. Remove the screws and the fastener.
5. Remove the bolt, then remove the cargo net hook.
6. Pull the trunk side trim outward and detach clips A and B.
7. Remove the trunk side trim.
8. Install in the reverse order of removal.

Scheme 81

Scheme 82

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-375422-S00139901402010102800000) .)
3. Remove the covers, then remove screws.
4. Detach clips A from the door trim using fastener remover.
5. Pull the door trim upward and detach tabs B from the door. CAUTION: Remove the front door trim being careful not to scratch area C of the sash film.
6. Disconnect the power outer mirror switch connector and the power window main switch connector.
7. Disconnect the door lock switch connector.
8. Remove the inner handle cover.
9. Remove the front door trim.
10. Install in the reverse order of removal.

Scheme 83

Scheme 84

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-375422-S00139901402010102800000) .)
3. Detach handle pull cover using a tape-wrapped flathead screwdriver as shown in the figure
4. Remove the covers, then remove screws.
5. Detach clips A from the door trim using fastener remover.
6. Pull the door trim upward and detach tabs B from the door. CAUTION: Remove the front door trim being careful not to scratch area C of the sash film.
7. Disconnect the power window subswitch connector.
8. Disconnect the door lock switch connector.
9. Remove the inner handle cover.
10. Remove the front door trim.
11. Install in the reverse order of removal.

Scheme 85

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Scheme 86

Scheme 87

1. Remove the tab A and B.
2. Remove the bracket.
3. Remove the handle pull.
4. Disassemble in the order indicated in the table.
5. Assemble in the reverse order of disassembly.

Scheme 88

Scheme 89

1. Disconnect the negative battery cable.
2. Remove the sail garnish. (See «SAIL GARNISH REMOVAL/INSTALLATION»(ref-375422-S24908364332010102800000) .)
3. Remove the covers.
4. Remove the screws.
5. Detach clips A from the door trim using fastener remover.
6. Pull the door trim upward and detach tabs B from the door. CAUTION: Remove the rear door trim being careful not to scratch areas C of the sash film.
7. Disconnect the power window subswitch connector.
8. Disconnect the door lock switch connector.
9. Remove the inner handle cover.
10. Remove the rear door trim.
11. Install in the reverse order of removal.

Scheme 90

1. Remove the screws.
2. Remove the sub trunk box.
3. Install in the reverse order of removal.

Scheme 91

1. Pull the liftgate upper trim and detach clips A and B, pin C.
2. Remove the liftgate upper trim.
3. Install in the reverse order of removal.

Scheme 92

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) .)
2. Remove the fastener.
3. Pull the liftgate side trim toward you, then disengage the clip A and pin B from the body.
4. Remove the tab C, E and clip D.
5. Remove the liftgate side trim.
6. Install in the reverse order of removal.

Scheme 93

Scheme 94

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) )
2. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05467767222010102800000) )
3. Pull the recess toward you, then remove it.
4. Remove the fasteners.
5. Pull the liftgate lower trim toward you, then disengage the clips A, B and pins C from the body.
6. Remove the liftgate lower trim.
7. Install in the reverse order of removal.

Scheme 95

Scheme 96

1. Insert a screwdriver into the assist handle notch and remove the assist handle cover.
2. Pull the assist handle outward, then remove the assist handle.
3. Install in the reverse order of removal.

Scheme 97

Scheme 98

1. Remove the screw, then remove the sunvisor.
2. Disconnect the vanity mirror illumination connector.
3. Disengage the center adapter (sunvisor stopper) from the body using a fastener remover.
4. Install in the reverse order of removal.

Scheme 99

Scheme 100

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: A-pillar lower trim (See «A-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S07484122802010102800000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S30388225242010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-375441-S36111913702010102800000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S41425861872010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S21530471642010102800000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S26389937922010102800000) .) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-375422-S31047308992010102800000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-375320-S33124507192010102800000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-375422-S14848166412010102800000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-375422-S01596377622010102800000) .)
4. Disconnect the rear washer hose.
5. Disconnect the roof harness connector.
6. Remove the fasteners.
7. Remove the sunroof seaming welt (vehicles with sunroof only)
8. Take the headliner out from the opened liftgate.
9. Install in the reverse order of removal.

Scheme 101

Scheme 102

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-375390-S38320566432010102800000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-375390-S34221810972010102800000) .) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S26643993712010102800000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S15162149412010102800000) .) Sub trunk box (See «SUB TRUNK BOX REMOVAL/INSTALLATION»(ref-375422-S36700633102010102800000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .) Trunk side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05467767222010102800000) .) Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-375378-S04018353012010102800000) .) Selector lever component bracket SAS control module (See «SAS CONTROL MODULE REMOVAL/INSTALLATION»(ref-375340-S03164898512010102800000) .) Console bracket
3. Cut away the floor covering as shown in the figure. NOTE: The cut part does not need to match up when installing the floor covering.
4. Remove fastener A, B, C and D.
5. Take the floor covering out from the opened liftgate.
6. Install in the reverse order of removal.
