Security System and Locks System: Overview Mazda CX-7 I рестайлинг

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Fully roll up the front door glass.
3. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-375422-S00139901402010102800000) .)
4. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S00088527812010102800000) .)
5. Remove the hole cover.
6. Detach the rod from the outer handle.
7. Secure the rear part of the front outer handle and, with the front outer handle lever pulled outward (1), remove the rear part of the front outer handle from the front door.
8. Pull out the front side of the front outer handle from the front door.
9. Install in the reverse order of removal.

Scheme 27

1. Disconnect the negative battery cable.
2. Fully roll up the rear door glass.
3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S34474239882010102800000) .)
4. Secure the rear part of the rear outer handle and, with the rear outer handle lever pulled outward (1), remove the rear part of the rear outer handle from the rear door.
5. Install in the reverse order of removal.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the front door trim or rear door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S00088527812010102800000) .) (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S34474239882010102800000) .)
3. Detach the cables from the inner handle and door lock knob.
4. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the inner handle cover. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S00088527812010102800000) .)
3. Remove the screws, then remove the door lock switch.
4. Install in the reverse order of removal.

Scheme 30

Scheme 31

1. Inspect for continuity between the door lock switch terminals using an ohmmeter. If not as specified, replace the door lock switch.

Scheme 32

1. To remove the hood release cable, remove the following parts
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
4. Adjust the hood. (See «HOOD ADJUSTMENT»(ref-375392-S19274227692010102800000) .)

Scheme 33

Scheme 34

Scheme 35

1. Pull the hood release lever.
2. While maintaining the condition in procedure 1, insert a tape-wrapped flathead screwdriver as shown in the figure, press the ends of the tabs with the screwdriver in the direction of the arrows (1), pull the hood release lever in the direction of arrow (2), and then disconnect the lower panel. CAUTION: Remove the hood release lever while being careful not to damage the hood release cable with the flathead screwdriver.
3. Pull the latch release lever outward, remove it from the lower panel, and then disconnect the hood release cable.
4. Install in the reverse order of removal.

Scheme 36

Scheme 37

Scheme 38

1. When inspecting the latch, press the latch lever using a flathead screwdriver or a similar tool.
2. Inspect for continuity between the hood latch switch terminals. If not as specified, replace the hood latch.

Scheme 39

1. Disconnect the negative battery cable.
2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-375422-S00139901402010102800000) .) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S00088527812010102800000) .) Front outer handle (See «FRONT OUTER HANDLE REMOVAL/INSTALLATION»(ref-375401-S38287474812010102800000) .)
3. Remove the rod from the front door key cylinder.
4. Turn the key cylinder in the direction indicated by the arrow and move the tab to the notch.
5. Pull the front door key cylinder outward to remove it.
6. Install in the reverse order of removal.

Scheme 40

Scheme 41

1. Inspect for continuity between the front door key cylinder switch terminals. If not as specified, replace the front door latch and lock actuator.

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-375422-S00139901402010102800000) .) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S00088527812010102800000) .) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-375321-S28210791422010102800000) .) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-375342-S10136009022010102800000) .) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-375401-S02053629342010102800000) .) Front door unit (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-375463-S25591096932010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 43

1. The following actuators and switches are integrated with the front door latch and lock actuator. Inspect the front door latch and lock actuator according to each inspection procedure for the following items. Front door lock actuator (See «FRONT DOOR LOCK ACTUATOR INSPECTION»(ref-375401-S22069741062010102800000) .) Front door key cylinder switch (Driver's side) (See «FRONT DOOR KEY CYLINDER SWITCH INSPECTION»(ref-375401-S39586462802010102800000) .) Door lock-link switch (See «DOOR LOCK-LINK SWITCH INSPECTION»(ref-375401-S33428254932010102800000) .)

Scheme 44

1. Apply battery positive voltage and connect ground to the corresponding front door lock actuator terminals, and inspect the front door lock actuator operation. If not as specified, replace the front door latch and lock actuator. LOCK ACTUATOR CONNECTION CHART Lock actuator operation Connection B+ GND Lock LH: 1A LH: 1B RH: 1B RH: 1A Unlock LH:1B LH: 1A RH:1A RH: 1B

Scheme 45

Scheme 46

1. Inspect for continuity between the door lock-link switch terminals. If not as specified, replace the front/rear door latch and lock actuator.

Scheme 47

1. Remove the screws, then remove the door lock striker.
2. Install in the reverse order of removal.
3. Adjust the door. (See «DOOR ADJUSTMENT»(ref-375463-S40833142512010102800000) .)

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the following parts: Front door trim (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-375422-S34474239882010102800000) .) Front door glass (See «REAR DOOR GLASS REMOVAL/INSTALLATION»(ref-375321-S42405400382010102800000) .) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-375342-S10136009022010102800000) .) Inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-375401-S02053629342010102800000) .) Rear door unit (See «REAR DOOR REMOVAL/INSTALLATION»(ref-375463-S32990709152010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 49

1. The following actuator and switch are integrated with the rear door latch and lock actuator. Inspect the rear door latch and lock actuator according to each inspection procedure for the following items. Rear door lock actuator (See «REAR DOOR LOCK ACTUATOR INSPECTION»(ref-375401-S39161577852010102800000) .) Door lock-link switch (See «DOOR LOCK-LINK SWITCH INSPECTION»(ref-375401-S33428254932010102800000) .)

Scheme 50

1. Apply battery positive voltage and connect ground to the corresponding front door lock actuator terminals, and inspect the front door lock actuator operation. If not as specified, replace the rear door latch and lock actuator. LOCK ACTUATOR CONNECTION CHART Lock actuator operation Connection B+ GND Lock LH: 1A LH:1B RH:1B RH:1A Unlock LH: 1B LH:1A RH:1A RH:1B

Scheme 51

1. Remove the rear finisher. (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-375375-S14706990682010102800000) .)
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 52

1. Disconnect the negative battery cable.
2. Remove the following parts Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-375422-S04325768492010102800000) .) Liftgate side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05467767222010102800000) .) Liftgate lower trim (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-375422-S12242040212010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 53

Scheme 54

Scheme 55

1. When inspecting the latch, press the latch lever using a flathead screwdriver or a similar tool.
2. Inspect for continuity between the liftgate latch switch terminals. If not as specified, replace the liftgate latch and lock actuator.

Scheme 56

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-375422-S17949797502010102800000) .)
2. Remove the bolts, then remove the liftgate lock striker.
3. Install in the reverse order of removal.
4. Adjust the liftgate. (See «LIFTGATE ADJUSTMENT»(ref-375463-S29698529922010102800000) .)

Scheme 57

1. Apply battery positive voltage and connect ground to the corresponding liftgate lock actuator terminals, and inspect the liftgate lock actuator operation. If not as specified, replace the liftgate latch and lock actuator. LOCK ACTUATOR CONNECTION CHART Lock actuator operation Connection B+ GND Lock A B Unlock B A

Scheme 58

1. If the keyless control module is replaced, always perform the following procedure. Keyless Control Module Configuration (See «KEYLESS CONTROL MODULE CONFIGURATION [ADVANCED KEYLESS ENTRY AND START SYSTEM]»(ref-375401-S23081393182010102800000) .) Immobilizer System-related Parts Programming [No.6 Programming Procedure Due to Keyless Control Module Replacement] (See «IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [ADVANCED KEYLESS ENTRY AND START SYSTEM]»(ref-375401-S42575042972010102800000) .)
2. Disconnect the negative battery cable.
3. Remove the front side trim. (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .)
4. Disconnect the keyless control module connector.
5. Remove the bolt, then remove the keyless control module.
6. Install in the reverse order of removal.
