GENERATOR REMOVAL/INSTALLATION [L5]
| WARNING | Remove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. When the battery cables are connected, touching the vehicle body with generator terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the negative battery cable before performing the following operation. |
| CAUTION | The generator can be damaged by the heat from the exhaust manifold. Make sure the generator duct is installed securely. |
Scheme 24
- Disconnect the negative battery cable.
- Remove the drive belt. (See «DRIVE BELT REMOVAL/INSTALLATION [L5]»(ref-375350-S06020913402010102800000) .)
- Remove the under cover.
- Remove the exhaust manifold insulator (upper). (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [L5]»(ref-375357-S38089501862010102800000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 25
Scheme 25: Generator Removal Note
- Remove the generator from above the engine compartment.
Generator Installation Note
- Tighten bolt A temporarily.
- Tighten bolt B, C to the specified tightening torque.
- Tighten bolt A to the specified tightening torque.
