Lighting Systems: Removal & Installation Mazda CX-7 I

Steering Column Switches 7 illustrations ~237 words

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)

Scheme 34

Scheme 34
Scheme 34
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-269043-S00980335112007102700000) ).
  3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-269051-S42065230672007102700000) .)
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

COMBINATION SWITCH REMOVAL/INSTALLATION

WARNINGIf the negative battery cable or the steering angle sensor connector is disconnected, the stored initial position of the steering angle sensor will be cleared and the DSC will not operate properly, making the vehicle unsafe to drive. Perform the steering angle sensor initialization procedure after connecting the negative battery cable.

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-269024-S06836863402007102700000) ). Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-269012-S00459439552007102700000) ). Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-269050-S25734514712007102700000) ).
  3. Remove in the order indicated in the table.
  4. Disconnect the steering angle sensor connector.
  5. Install in the reverse order of removal.
  6. Perform the steering angle sensor reference point setting. (See «STEERING ANGLE SENSOR INITIALIZATION PROCEDURE»(ref-269056-S25954096642007102700000) ).

Switch Bezel Component Removal Note

  1. Access the switch bezel component from behind of the dashboard, and squeeze the tabs of the switch bezel component.
  2. Remove the switch bezel component from the dashboard.

Scheme 36

Scheme 36: HEADLIGHT LEVELING SWITCH INSPECTION
Scheme 36: HEADLIGHT LEVELING SWITCH INSPECTION

Scheme 37

Scheme 37
Scheme 37
  1. Verify that continuity between the headlight leveling switch terminals is as indicated in the table. If not as indicated in the table, replace the headlight leveling switch.

Scheme 38

Scheme 38: With DRL
Scheme 38: With DRL

Scheme 39

Scheme 39: Without DRL
Scheme 39: Without DRL

Scheme 40

Scheme 40: AUTO LIGHT SENSOR REMOVAL/INSTALLATION
Scheme 40: AUTO LIGHT SENSOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover (RH).
  3. Push out the auto light sensor with connector from under the instrument panel
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
