Starting/charging — Starting circuit Mazda CX-5 II
All systems — 38 systems
- Air conditioning 2.2l turbo diesel
- Air conditioning 2.5l skyactiv
- Air conditioning 2.5l turbo skyactiv
- Anti-lock brakes
- Anti-theft
- Body control modules 2
- Computer data lines
- Cooling fan 2.2l turbo diesel
- Cooling fan 2.5l skyactiv
- Cooling fan 2.5l turbo skyactiv
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.2l turbo diesel
- Engine performance 2.5l skyactiv 2
- Engine performance 2.5l turbo skyactiv
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 5
- Power top/sunroof
- Power windows 2
- Radio 5
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 17
Click a component to highlight it on every diagram it appears on.
