Seat System: Other Mazda CX-5 I

Passenger-side

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

1. Switch the ignition off (LOCK).
2. Disconnect the negative battery cable and wait for 1 min. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Using a tape-wrapped flathead screwdriver, detach tab A in the direction of arrows (1) shown in the figure. (Scheme 165): Moving Flathead Screwdriver Wrapped In Protective Tape (1)
4. Using a tape-wrapped flathead screwdriver, detach tab B in the direction of arrows (2) shown in the figure. (Scheme 166): Moving Flathead Screwdriver Wrapped In Protective Tape (2)
5. Remove the recliner lever knob in the direction of the arrow (3) shown in the figure.
6. Remove clip C from the front seat cushion frame. (Scheme 167): Removing Recliner Lever Knob (Scheme 168): Removing Clip From Front Seat Cushion Frame
7. Pull up the front seat side cover in the direction of the arrow (4) shown in the figure and set hook D aside.
8. Pull the front seat side cover in the direction of the arrow (5) shown in the figure and disengage the tabs E and F, and the pin.
9. Pull the front seat side cover in the direction of the arrow (6) shown in the figure and set hook G aside. (Scheme 169): Pulling Front Seat Side Cover (Scheme 170): Removing Front Seat Side Cover
10. Pull the front seat side cover in the direction of the arrow (7) shown in the figure and set hook H aside.
11. Remove the front seat side cover
12. Install in the reverse order of removal.

Scheme 171

Scheme 172

Scheme 173

1. Switch the ignition off (LOCK).
2. Disconnect the negative battery cable and wait for 1 min. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-615443-S08848515662014051000000) ).
4. Remove the screw A.
5. Pull up the front seat side cover in the direction of the arrow (1) shown in the figure and set hook B aside. (Scheme 171): Pulling Up Front Seat Side Cover
6. Pull the front seat side cover in the direction of the arrow (2) shown in the figure and disengage the tabs C and D, and the pin. (Scheme 172): Removing Front Seat Side Cover
7. Pull the front seat side cover in the direction of the arrow (3) shown in the figure and set hook E aside. (Scheme 173): Removing Front Seat Side Cover
8. Pull the front seat side cover in the direction of the arrow (4) shown in the figure and set hook F aside.
9. Remove the front seat side cover.
10. Install in the reverse order of removal.

Forward

1. When performing an asterisked (*) troubleshooting inspection, shake the wiring harness and connectors while performing the inspection to discover whether poor contact points are the cause of any intermittent malfunction. If there is a problem, inspect to make sure connectors, terminals and wiring harnesses are connected correctly and undamaged.

Seat Warmer Control Unit - System Diagram. Scheme 174

Seat back side

1. Switch the ignition to off.
2. Disconnect the negative battery cable and wait 1 min. or more. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-615443-S08848515662014051000000) ).
4. Inspect for continuity between the seat warmer unit connector (short code) terminal A-B. If not as specified, replace the front seat back pad. (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-615443-S27007608072014051000000) ). see scheme 188: Checking Continuity Between Seat Warmer Unit Connector Terminal (A And B) see scheme 189: Identifying Seat Warmer Unit Driver Side (Seat Back Side)

Scheme 175

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Press the push knob to fold the rear seat back.
3. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ).
4. Remove the bolts.
5. Remove the rear seat back striker.
6. Install in the reverse order of removal. (Scheme 175): Identifying Rear Seat Back Striker And Bolts With Torque Specifications

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

1. Operate the push knob (RH) and lower the rear seat back (RH)
2. Remove screw A.
3. Remove the rear seat center armrest hinge cover (RH) in the direction of the arrow (1) shown in the figure while setting hook A aside. (Scheme 176): Removing Rear Seat Center Armrest Hinge Cover (RH)
4. Remove bolt B.
5. Remove the rear seat center armrest in the direction of the arrow (2) shown in the figure while setting the pins aside. (Scheme 177): Identifying Rear Seat Center Armrest Bolts With Torque Specifications (Scheme 178): Identifying Rear Seat Center Armrest Hinge Cover Pin
6. Using a flathead screwdriver wrapped in protective tape, insert it in the gap between the cup holder and the rear seat center armrest in the direction of the arrow (3) shown in the figure, and disengage tabs B. (Scheme 179): Inserting Flathead Screwdriver In Gap Between Cup Holder And Rear Seat Center Armrest
7. Using a flathead screwdriver wrapped in protective tape, insert it in the gap between the cup holder and the rear seat center armrest in the direction of the arrow (4) shown in the figure, and disengage tabs C. (Scheme 180): Inserting Flathead Screwdriver In Gap Between Cup Holder And Rear Seat Center Armrest
8. Remove the cup holder in the direction of the arrow (5) shown in the figure.
9. Install in the reverse order of removal. (Scheme 181): Removing Cup Holder

Scheme 182

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ).
3. Disconnect the remote cable on the remote handle lever side from the remote cable on the rear seat side. (Scheme 182): Disconnecting Remote Cable
4. Remove the remote cable on the remote handle lever side from the clip.
5. Pull out the remote cable on the remote handle lever side from the band in the direction of the arrow shown in the figure, and remove the remove handle lever.
6. Install in the reverse order of removal. (See «REMOTE HANDLE LEVER INSTALLATION NOTE»(ref-615443-S05398081372014051000000) ).

Remote cable

Scheme 183

1. Install the remote cables according to the following procedure. Route the remote cables (center) under the rear hinge as shown in the figure. Route the remote cables (LH/RH) through the ISO FIX anchors from top to bottom as shown in the figure. Place the case on the mat behind the rear seat cushion. (Scheme 183): Identifying Rear Hinge, ISO FIX Anchor, Case And Remote Cable (LH And RH)
2. After installing the remote cables, wobble the rear seat backs forward and back to verify that the rear seat backs are securely locked into the rear seat back strikers. NOTE: If there is a malfunction in locking, adjust the fixed position of the cable in the case.
