When Not Using the M-MDS Mazda CX-5 I

Lighting System 3 illustrations ~356 words

When Not Using the M-MDS

CAUTIONPerform Steps 3 - 4 within 30 s.

Scheme 180

Scheme 180
Scheme 180
  1. Empty the vehicle by having all occupants leave the vehicle and remove all the cargo except for the spare tire, jack and tools equipped on the vehicle.
  2. Adjust the air pressure of each tire to the specified value. (See «WHEEL AND TIRE SPECIFICATION»(ref-615392-S30588016422014051000000) ).
  3. Switch the ignition ON (engine off or on). NOTE: The AFS OFF indicator light continues flashing during the first initial setting, however, continue the work because it does not indicate an improper procedure.
  4. Using a jumper wire, connect DLC-2 terminals B and J (ground) three times at 0.5 to 1.5 s intervals as shown in the figure. see scheme 174: Identifying AFS Off Indicator Light CAUTION: If the terminals are mistakenly connected, vehicle damage or fire could occur. When connecting with the jumper wire, thoroughly verify what terminals are being connected to prevent a miss-connection. (Scheme 180): Identifying Connector Terminal
  5. Verify the AFS OFF indicator light. If the AFS OFF indicator light flashes three times at 0.25 s intervals and turns off as shown in the figure, the initial setting is completed. Go to the next step. If the AFS OFF indicator light continues flashing, the procedure may be performed incorrectly. Repeat the procedure from Step 1. If the AFS OFF indicator light is illuminated, the headlight auto leveling system may have a malfunction. Perform the DTC inspection. (See «DTC INSPECTION [ADAPTIVE FRONT LIGHTING SYSTEM (AFS)]»(ref-615487-S42645478812014051000000) ). Repair or replace the malfunctioning area, then repeat the procedure from Step 1. see scheme 176: AFS Off Indicator Light Timing Mode Pattern
  6. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-615452-S25587632522014051000000) ).

Scheme 181

Scheme 181: BACK-UP LIGHT SWITCH INSPECTION
Scheme 181: BACK-UP LIGHT SWITCH INSPECTION

Scheme 182

Scheme 182
Scheme 182
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the front under cover No.2. (See «FRONT UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-615433-S21444705852014051000000) ).
  3. Remove the back-up light switch. (See «BACK-UP LIGHT SWITCH REMOVAL/INSTALLATION [C66M-R]»(ref-615415-S14733546552014051000000) ). (Scheme 181): Continuity Reference Chart
  4. Verify that the continuity between the back-up light switch terminals is as indicated in the table. If not as indicated in the table, replace the back-up light switch. (Scheme 182): Identifying Back-Up Light Switch Connectors
