IGNITER REMOVAL/INSTALLATION Mazda CX-5 I

Lighting System: Removal & Installation 11 illustrations ~506 words

IGNITER REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS ).

Scheme 25

Scheme 25: Igniter (LH)
Scheme 25: Igniter (LH)

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the air cleaner cover. (See «AIR CLEANER ELEMENT REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615404-S15488888472014051000000) ).
  3. Remove the relay and fuse block upper cover. (See «RELAY AND FUSE BLOCK REMOVAL/INSTALLATION»(ref-615398-S32369581092014051000000) ).
  4. Remove the nut and screw. (Scheme 25): Identifying Relay And Fuse Block With Mounting Nut And Screw With Torque Specifications
  5. Insert a tape-wrapped flathead screwdriver into the service hole in the position shown in the figure. (Scheme 26): Identifying Relay And Fuse Block Service Hole Position
  6. While pressing the pin tab in the direction of the arrow (1) shown in the figure using a flathead screwdriver, pull the pin in the direction of the arrow (2) shown in the figure to detach the pin tab and engine mount. (Scheme 27): Pressing Pin Tab Using Flathead Screwdriver
  7. Pull out the relay and fuse block from the stud bolt and set it aside as shown in the figure. (Scheme 28): Pulling Out Relay And Fuse Block From Stud Bolt
  8. Rotate the cover in the direction of the arrow (3) shown in the figure and remove it from the front combination light in the direction of the arrow (4) shown in the figure. (Scheme 29): Removing Cover From Front Combination Light
  9. Rotate the igniter in the direction of the arrow (5) shown in the figure and remove it from the front combination light in the direction of the arrow (6) shown in the figure. (Scheme 30): Removing Igniter From Front Combination Light
  10. Insert the flathead screwdriver into the gap between the igniter and connector shown in the figure. (Scheme 31): Identifying Flathead Screwdriver Hole Insertion Position
  11. Move the flathead screwdriver in the direction of the arrow (7) shown in the figure, lift up the connector, and disconnect it.
  12. Install in the reverse order of removal. (Scheme 32): Removing Connector From Igniter Using Flathead Screwdriver

Scheme 33

Scheme 33: Igniter (RH)
Scheme 33: Igniter (RH)

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the washer tank bracket. (See «WASHER TANK REMOVAL/INSTALLATION»(ref-615468-S33892862142014051000000) ).
  3. Rotate the cover in the direction of the arrow (1) shown in the figure and remove it from the front combination light in the direction of the arrow (2) shown in the figure. (Scheme 33): Removing Cover From Front Combination Light
  4. Rotate the igniter in the direction of the arrow (3) shown in the figure and remove it from the front combination light in the direction of the arrow (4) shown in the figure. (Scheme 34): Removing Igniter From Front Combination Light
  5. Insert the flathead screwdriver into the gap between the igniter and connector shown in the figure. see scheme 49: Identifying Flathead Screwdriver Hole Insertion Position
  6. Move the flathead screwdriver in the direction of the arrow (5) shown in the figure, lift up the connector, and disconnect it.
  7. Install in the reverse order of removal. (Scheme 35): Removing Connector From Igniter Using Flathead Screwdriver
