Lighting System: Overview Mazda CX-5 I

Exterior Lights 5 illustrations ~237 words
Fig. 1: Lighting Systems Components Location - Exterior (1 Of 2)
Scheme 1: Lighting Systems Components Location - Exterior (1 Of 2)
Fig. 2: Lighting Systems Components Location - Exterior (2 Of 2)
Scheme 2: Lighting Systems Components Location - Exterior (2 Of 2)
Fig. 3: Lighting Systems Components Location (Interior)
Scheme 3: Lighting Systems Components Location (Interior)

Scheme 1

Scheme 1: Discharge Headlight Service Warnings
Scheme 1: Discharge Headlight Service Warnings
  1. When replacing a discharge headlight bulb, performing the servicing with the negative battery cable connected or in a wet work area could result in electrocution. When replacing a discharge headlight bulb, perform the servicing under the following conditions: Switch the ignition to off and disconnect the negative battery cable. Perform the servicing out of the rain and in a dry work area. Thoroughly dry your hands.
  2. Because the discharge headlight bulb connector instantly produces approx. 25,000 V of high voltage, inserting a finger or a tester probe could result in electrocution. When turning the light switch on, do not insert a finger or tester probe into the discharge headlight bulb connector.
  3. If a discharge headlight bulb is illuminated before completely assembling the discharge headlight related parts to a front combination light, it could result in electrocution. Before illuminating the discharge headlights, completely assemble the discharge headlight related parts to the front combination lights and install the front combination lights to the vehicle. (Scheme 1): Precaution For Discharge Headlight Bulb Connector

Scheme 2

Scheme 2: Discharge Headlight Control Module Servicing Warnings
Scheme 2: Discharge Headlight Control Module Servicing Warnings
  1. If the discharge headlight control module tester is used to do a part inspection or the discharge headlight control module is disassembled, electrocution could result from the high voltage around the module. Do not do a part inspection of or disassemble the discharge headlight control module. (Scheme 2): Precaution For Discharge Headlight Control Module
