  1. Switch the ignition ON (engine off or on).
  2. Turn the audio unit power on.
  3. Select the following from the audio unit screen. "Setup" "Vehicle" "Door Locks"
  4. Select the following items and change the setting. ADVANCED KEYLESS ENTRY SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Auto Re-lock Time The operation start time of the auto re-lock function can be changed. 60 seconds 30 seconds/60 seconds/90 seconds Start stop unit Lock Beep Volume The keyless beeper volume can be adjusted. Medium Off/Low/Medium/High Start stop unit Walk Away Lock The out-of-area (reception area) type auto lock function can be set. OFF OFF/ON Start stop unit KEYLESS ENTRY SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Auto Re-lock Time The operation start time of the auto re-lock function can be changed. 60 seconds 30 seconds/60 seconds/90 seconds Start stop unit POWER DOOR LOCK SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Unlock Mode 2-step unlocking system can be set. Once Driver's, Twice: All Doors Touch Once: ALL Doors/Once Driver's, Twice: All Doors Start stop unit Auto Door Lock Mode Auto door lock function can be changed. Lock: Driving, Unlock: IGN Off OFF/Lock When Driving/Lock: Driving, Unlock: IGN Off/Lock When Shifting Out Of P/Lock: Shift From P, Unlock: In P Rear body control module (RBCM)

Lighting Systems

  1. Switch the ignition ON (engine off or on).
  2. Turn the audio unit power on.
  3. Select the following from the audio unit screen. "Setup" "Vehicle" "Lighting"
  4. Select the following items and change the setting. TURN LIGHT SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module 3-Flash Turn Signal The turn light system can be switched between operable and inoperable. On On/Off Rear body control module (RBCM) AUTO LIGHT SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Auto-headlight On Auto light sensor sensitivity can be changed. Medium Light/Medium Light/Medium/Medium Dark/Dark Rear body control module (RBCM) NOTE: If the mode is set to "Light" and "Medium Light", the illumination level for illuminating the TNS and headlight increases. Therefore, the TNS and headlights illuminate when the ambient light is brighter than when the level is set to "Medium". In addition, if the mode is set to "Medium Dark" and "Dark", the illumination level for illuminating the TNS and headlights decreases. Therefore, the TNS and headlights illuminate when the ambient light is lower than when the level is set to "Medium". AUTO LIGHT OFF SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Headlight Off Timer The headlight emitted time of the auto light off timer can be changed. 30 seconds. 120 seconds./90 seconds./60 seconds./30 seconds./0 seconds. Rear body control module (RBCM) ROOM LIGHT CONTROL SYSTEM DESCRIPTION Audio unit display Function Initial setting Setting contents Control module Interior Light Timeout - Door Open The front/rear map light illumination time after any door is open can be changed. 30 minutes 60 minutes/30 minutes/10 minutes Rear body control module (RBCM) Interior Light Timeout - Door Closed The front/rear map light illumination time after any door is closed can be changed. 15 seconds 60 seconds/30 seconds/15 seconds/7.5 seconds Rear body control module (RBCM)

Without Bose®

Note. If the procedure is performed while holding the front door speaker cone, it could deform the cone causing a malfunction. Therefore, perform the procedure while holding any part other than the cone.

Scheme 79

Scheme 79: Without Bose®
Scheme 79: Without Bose®

Scheme 80

Scheme 80
Scheme 80
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-615455-S13279173212014051000000) ) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S36547034772014051000000) ).
  3. Disconnect the connector. (Scheme 79): Identifying Connector, Front Door Speakers With Torque Specifications (LH And RH)
  4. Remove the bolts in alphabetical order.
  5. Pull the front door speaker in the direction of the arrow shown in the figure and remove it while detaching the pins.
  6. Install in the reverse order of removal. (Scheme 80): Removing Front Door Speaker

Scheme 81

Scheme 81: With Bose®
Scheme 81: With Bose®

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-615455-S13279173212014051000000) ) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S36547034772014051000000) ).
  3. Disconnect the connector. (Scheme 81): Identifying Connector, Front Door Speakers With Torque Specifications (LH And RH)
  4. Remove the bolts in alphabetical order.
  5. Pull the front door speaker in the direction of the arrow shown in the figure and remove it while detaching the pins. (Scheme 82): Removing Front Door Speaker
  6. Remove the screws.
  7. Remove the front door speaker from the bracket.
  8. Install in the reverse order of removal. (Scheme 83): Identifying Front Door Speaker, Bracket And Screws

Scheme 84

Scheme 84: FRONT DOOR SPEAKER INSPECTION
Scheme 84: FRONT DOOR SPEAKER INSPECTION
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-615455-S13279173212014051000000) ) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S36547034772014051000000) ).
  3. Disconnect the front door speaker connector. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S00203104652014051000000) ).
  4. Verify that the resistance and continuity between the front door speaker terminals is as indicated in the table. If not as indicated in the table, replace the front door speaker. (Scheme 84): Front Door Speaker Continuity Reference Chart (Without Bose)

Front Door Speaker Continuity Reference Chart (With Bose). Scheme 85

Scheme 85: Front Door Speaker Continuity Reference Chart (With Bose)
Scheme 85: Front Door Speaker Continuity Reference Chart (With Bose)

Note. If the procedure is performed while holding the front door speaker cone, it could deform the cone causing a malfunction. Therefore, perform the procedure while holding any part other than the cone.

Scheme 86

Scheme 86: Without Bose®
Scheme 86: Without Bose®

Scheme 87

Scheme 87
Scheme 87
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ).
  3. Disconnect the connector. (Scheme 86): Identifying Connector, Rear Door Speakers With Torque Specifications (LH And RH)
  4. Remove the bolts in alphabetical order.
  5. Pull the rear door speaker in the direction of the arrow shown in the figure and remove it while detaching the pins.
  6. Install in the reverse order of removal. (Scheme 87): Removing Rear Door Speaker

Scheme 88

Scheme 88: With Bose®
Scheme 88: With Bose®

Scheme 89

Scheme 89
Scheme 89
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ).
  3. Disconnect the connector. (Scheme 88): Identifying Connector, Rear Door Speakers With Torque Specifications (LH And RH)
  4. Remove the bolts in alphabetical order.
  5. Pull the rear door speaker in the direction of the arrow shown in the figure and remove it while detaching the pins.
  6. Install in the reverse order of removal. (Scheme 89): Removing Rear Door Speaker

Scheme 90

Scheme 90: REAR DOOR SPEAKER INSPECTION
Scheme 90: REAR DOOR SPEAKER INSPECTION
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ).
  3. Disconnect the rear door speaker connector. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S07587056722014051000000) ).
  4. Verify that the resistance between the rear door speaker terminals is as indicated in the table. If not as indicated in the table, replace the rear door speaker. (Scheme 90): Rear Door Speaker Continuity Reference Chart (Without Bose)

Rear Door Speaker Continuity Reference Chart (With Bose). Scheme 91

Scheme 91: Rear Door Speaker Continuity Reference Chart (With Bose)
Scheme 91: Rear Door Speaker Continuity Reference Chart (With Bose)

Scheme 92

Scheme 92: FRONT CENTER SPEAKER REMOVAL/INSTALLATION
Scheme 92: FRONT CENTER SPEAKER REMOVAL/INSTALLATION

Scheme 93

Scheme 93
Scheme 93
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the center speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-615455-S06843686952014051000000) ).
  3. Remove the screws.
  4. Remove the front center speaker. (Scheme 92): Identifying Front Center Speaker And Mounting Screws With Torque Specifications
  5. Disconnect the connector.
  6. Install in the reverse order of removal. (Scheme 93): Identifying Front Center Speaker And Connector

Scheme 94

Scheme 94: FRONT CENTER SPEAKER INSPECTION
Scheme 94: FRONT CENTER SPEAKER INSPECTION

Scheme 95

Scheme 95
Scheme 95
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the center speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-615455-S06843686952014051000000) ).
  3. Remove the front center speaker. (See «FRONT CENTER SPEAKER REMOVAL/INSTALLATION»(ref-615447-S24674338632014051000000) ).
  4. Verify that the resistance between the front center speaker terminals is as indicated in the table. If not as indicated in the table, replace the front center speaker. (Scheme 94): Front Center Speaker Continuity Reference Chart (Scheme 95): Checking Resistance Between Front Center Speaker Terminals

Scheme 96

Scheme 96: TWEETER REMOVAL/INSTALLATION
Scheme 96: TWEETER REMOVAL/INSTALLATION

Scheme 97

Scheme 97
Scheme 97
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the side speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-615455-S06843686952014051000000) ).
  3. Remove the screws. (Scheme 96): Identifying Tweeter And Screws
  4. Pull out the tweeter and disconnect the connector.
  5. Install in the reverse order of removal. (Scheme 97): Identifying Tweeter And Connector

Scheme 98

Scheme 98: TWEETER INSPECTION
Scheme 98: TWEETER INSPECTION
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the side speaker grille. (See «SPEAKER GRILLE REMOVAL/INSTALLATION»(ref-615455-S06843686952014051000000) ).
  3. Remove the tweeter. (See «TWEETER REMOVAL/INSTALLATION»(ref-615447-S29571754762014051000000) ).
  4. Verify that the resistance between the tweeter terminals is as indicated in the table. If not as indicated in the table, replace the tweeter. (Scheme 98): Tweeter Continuity Reference Chart (Without Bose)

Tweeter Continuity Reference Chart (With Bose). Scheme 99

Scheme 99: Tweeter Continuity Reference Chart (With Bose)
Scheme 99: Tweeter Continuity Reference Chart (With Bose)

Scheme 100

Scheme 100: D-PILLAR SPEAKER REMOVAL/INSTALLATION
Scheme 100: D-PILLAR SPEAKER REMOVAL/INSTALLATION

Scheme 101

Scheme 101
Scheme 101
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ).
  3. Disconnect the connector.
  4. Remove the screws.
  5. Remove the D-pillar speaker. (Scheme 100): Identifying D-pillar Speaker, Trim, Connector And Screws
  6. While pressing the tabs of the clip in the direction of the arrow (1) shown in the figure, press it in the direction of the arrow (2) to detach the short-cord clip from the D-pillar trim.
  7. Remove the short cord.
  8. Install in the reverse order of removal. (Scheme 101): Detaching Short-Cord Clip From D-Pillar Trim

Scheme 102

Scheme 102: D-Pillar Speaker
Scheme 102: D-Pillar Speaker
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ).
  3. Disconnect the D-pillar speaker connector. (See «D-PILLAR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S27522353462014051000000) ).
  4. Verify that the resistance between the D-pillar speaker terminals is as indicated in the table. If not as indicated in the table, replace the D-pillar speaker. (Scheme 102): D-Pillar Speaker Continuity Reference Chart see scheme 46: Checking Resistance Between D-Pillar Speaker Terminals

Scheme 103

Scheme 103: Short-cord
Scheme 103: Short-cord

Scheme 104

Scheme 104
Scheme 104
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the following parts: Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ).
  3. Disconnect the D-pillar speaker connector. (See «D-PILLAR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S27522353462014051000000) ).
  4. Verify that the continuity between the short-cord terminals is as indicated in the table. If not as indicated in the table, replace the short-cord. (Scheme 103): D-Pillar Speaker Continuity Reference Chart (Scheme 104): Checking Continuity Between Short-Cord Terminals

Without Bluetooth System

WARNINGHandling the driver-side air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS [TWO-STEP DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE CAUTIONS [TWO-STEP DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE WARNINGS [STANDARD DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE CAUTIONS [STANDARD DEPLOYMENT CONTROL SYSTEM] ).

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109
  1. Switch the ignition OFF (LOCK).
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-615424-S35878193132014051000000) ). (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-615423-S04013315272014051000000) ).
  4. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-615435-S37273804732014051000000) ).
  5. Verify that the resistance and continuity between the steering switch terminals is as indicated in the table. (Scheme 105): Checking Resistance And Continuity Between Steering Switch Terminals (Without Bluetooth System) If not as indicated in the table, replace the steering switch. (See «STEERING SWITCH REMOVAL/INSTALLATION»(ref-615447-S30405949622014051000000) ). (Scheme 106): Steering Switch Continuity Reference Chart (Terminal H And J) (Scheme 107): Steering Switch Continuity Reference Chart (Terminal D And L) (Scheme 108): Steering Switch Continuity Reference Chart (Terminal D And L)
  6. Apply battery positive voltage to steering switch terminal F, and connect terminal B to ground.
  7. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch. (See «STEERING SWITCH REMOVAL/INSTALLATION»(ref-615447-S30405949622014051000000) ). (Scheme 109): Application Battery Positive Voltage To Steering Switch Terminals

With Bluetooth System

WARNINGHandling the driver-side air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS [TWO-STEP DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE CAUTIONS [TWO-STEP DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE WARNINGS [STANDARD DEPLOYMENT CONTROL SYSTEM] ). (See AIR BAG SYSTEM SERVICE CAUTIONS [STANDARD DEPLOYMENT CONTROL SYSTEM] ).

Scheme 110

Scheme 110
Scheme 110

Scheme 111

Scheme 111
Scheme 111

Scheme 112

Scheme 112
Scheme 112
  1. Switch the ignition OFF (LOCK).
  2. Disconnect the negative battery cable and wait for 1 min or more. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-615424-S35878193132014051000000) ). (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-615423-S04013315272014051000000) ).
  4. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-615435-S37273804732014051000000) ).
  5. Verify that the resistance and continuity between the steering switch terminals is as indicated in the table. (Scheme 110): Checking Resistance And Continuity Between Steering Switch Terminals (With Bluetooth System) If not as indicated in the table, replace the steering switch. (See «STEERING SWITCH REMOVAL/INSTALLATION»(ref-615447-S30405949622014051000000) ). (Scheme 111): Steering Switch Continuity Reference Chart (Terminal H And J) (Scheme 112): Steering Switch Continuity Reference Chart (Terminal M And J) see scheme 109: Steering Switch Continuity Reference Chart (Terminal D And L) see scheme 110: Steering Switch Continuity Reference Chart (Terminal D And L)
  6. Apply battery positive voltage to steering switch terminal F, and connect terminal B to ground.
  7. Verify that the LED illuminates. If the LED does not illuminate, replace the steering switch. (See «STEERING SWITCH REMOVAL/INSTALLATION»(ref-615447-S30405949622014051000000) ). see scheme 111: Application Battery Positive Voltage To Steering Switch Terminals

Scheme 113

Scheme 113: MICROPHONE REMOVAL/INSTALLATION
Scheme 113: MICROPHONE REMOVAL/INSTALLATION

Scheme 114

Scheme 114
Scheme 114
  1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
  2. Remove the front map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-615452-S19821275172014051000000) ).
  3. While pressing tabs A of the voice recognition microphone in the direction of the arrows (1) shown in the figure using a tape-wrapped flathead screwdriver, pull the voice recognition microphone in the direction of the arrow (2) shown in the figure to detach tabs A of the voice recognition microphone from the front map light. (Scheme 113): Removing Voice Recognition Microphone (Tab A) Using Tape-Wrapped Flathead Screwdriver
  4. While pulling tab B of the voice recognition microphone in the direction of the arrow (1) shown in the figure, pull the voice recognition microphone in the direction of the arrow (2) shown in the figure to detach tab B of the voice recognition microphone from the front map light. (Scheme 114): Removing Voice Recognition Microphone (Tab B) Using Tape-Wrapped Flathead Screwdriver
  5. Remove the voice recognition microphone.
  6. Install in the reverse order of removal.
