Engine Controls - Sensor Operating Range Charts: Other Mazda 626 GF

Sensor Range Charts 3 illustrations ~159 words

CRANKSHAFT POSITION (CKP) SENSOR

Application(1) Ohms
B2500, B3000 & B4000 (1)300-800
Miata(2)
Millenia 2.3L950-1250
Millenia 2.5L & 626 (3)520-580
Protege (3)500-600
(1) Measure resistance between CKP sensor terminals. Specification is with sensor temperature at 68°F (20°C) (2) Information not available from manufacturer. (3) Measure resistance between sensor terminals "A" and "B". (Scheme 1) Specification is with sensor temperature at 68°F (20°C).
(1)Measure resistance between CKP sensor terminals. Specification is with sensor temperature at 68°F (20°C)
(2)Information not available from manufacturer.
(3)Measure resistance between sensor terminals "A" and "B". (Scheme 1) Specification is with sensor temperature at 68°F (20°C).

CRANKSHAFT POSITION SENSOR RESISTANCE

Scheme 1

Scheme 1
Scheme 1

DIFFERENTIAL PRESSURE FEEDBACK EGR (DPFE) SENSOR

Pressure (psi)In. Hg(1) Volts
4.348.834.56
3.256.623.54
2.174.412.51
1.082.211.48
0.00.00.5
(1) Voltage specifications are calculated for a VREF equaling 5 volts. Specification may differ by as much as 15 percent.
(1)Voltage specifications are calculated for a VREF equaling 5 volts. Specification may differ by as much as 15 percent.

DIFFERENTIAL PRESSURE FEEDBACK EGR (DPFE) SENSOR VOLTAGE (B2500, B3000 & B4000)

ENGINE COOLANT TEMPERATURE (ECT) SENSOR

Temperature °F (°C)(1) PID VoltageOhms
50 (10)3.5258,750
68 (20)3.0637,300
86 (30)2.6224,270
104 (40)2.1616,150
122 (50)1.7010,970
140 (60)1.357600
158 (70)1.045370
176 (80)0.803840
194 (90)0.612800
212 (100)0.472070
230 (110)0.361550
248 (120)0.281180
(1) Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.
(1)Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.

ENGINE COOLANT TEMPERATURE (ECT) SENSOR SPECIFICATIONS (B2500, B3000 & B4000)

Temperature °F (°C)Ohms
Miata & Protege (1)
68 (20)2200-2700
176 (80)290-350
Millenia (2)
68 (20)2200-2700
176 (80)290-350
626 (2)
68 (20)35,500-39,200
176 (80)7180-7920
(1) Measure resistance between ECT sensor terminals "A" and "B". (Scheme 2)or (Scheme 3). (2) Measure resistance between ECT sensor terminals.
(1)Measure resistance between ECT sensor terminals "A" and "B". (Scheme 2)or (Scheme 3).
(2)Measure resistance between ECT sensor terminals.

ENGINE COOLANT TEMPERATURE (ECT) SENSOR RESISTANCE (EXCEPT B2500, B3000 & B4000)

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

INTAKE AIR TEMPERATURE (IAT) SENSOR

Note. IAT sensor on Protege 1.8L is part of Mass Airflow (MAF) sensor. See SYSTEM & COMPONENT TESTING - EXCEPT B2500, B3000 & B4000 article.

Temperature °F (°C)(1) PID Voltage(2) Ohms
50 (10)3.5258,750
68 (20)3.0637,300
86 (30)2.6224,270
104 (40)2.1616,150
122 (50)1.7010,970
140 (60)1.357600
158 (70)1.045370
176 (80)0.803840
194 (900.612800
212 (1000.472070
230 (1100.361550
248 (120)0.281180
(1) Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column. (2) Measure resistance between IAT sensor terminals.
(1)Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.
(2)Measure resistance between IAT sensor terminals.

INTAKE AIR TEMPERATURE (IAT) SENSOR SPECIFICATIONS (B2500, B3000 & B4000)

Temperature °F (°C)(1) Ohms
IAT Sensor (Air Cleaner Housing)
68 (20)2200-2700
176 (80)290-350
IAT Sensor (Dynamic Chamber)
77 (25)29,700-36,300
185 (85)3330-3670
IAT Sensor (Lysolm Compressor)
212 (100)5600-6900
(1) Measure resistance between IAT sensor terminals.
(1)Measure resistance between IAT sensor terminals.

INTAKE AIR TEMPERATURE (IAT) SENSOR RESISTANCE (MILLENIA 2.3L)

Temperature °F (°C)(1) Ohms
Miata
68 (20)2090-2810
176 (80)274-370
Millenia 2.5L
68 (20)2200-2700
176 (80)290-350
Protege 1.6L
50 (10)3100-4400
68 (20)2200-2700
86 (30)1400-1900
Protege 1.8L
68 (20)2200-2700
176 (80)270-370
626
68 (20)35,500-39,200
176 (80)7180-7920
(1) Measure resistance between IAT sensor terminals.
(1)Measure resistance between IAT sensor terminals.

INTAKE AIR TEMPERATURE SENSOR RESISTANCE (MIATA, MILLENIA 2.5L, PROTEGE & 626)

KNOCK SENSOR

Temperature °F (°C)(1) Ohms
68 (20)560,000
(1) Measure resistance between terminal "A" (White wire on Miata and 626, Red wire on Millenia 2.3L) and knock sensor body.
(1)Measure resistance between terminal "A" (White wire on Miata and 626, Red wire on Millenia 2.3L) and knock sensor body.

KNOCK SENSOR RESISTANCE (MIATA, MILLENIA & 626)

MASS AIRFLOW (MAF) SENSOR

Condition(1) Volts
Miata
Ignition On1.5
Idle1.9-2.0
Millenia
Ignition On1.3-1.5
Idle1.5-3.0
Protege
1.6L
Ignition On.9-2.0
Idle1.7-2.4
1.8L
Ignition On.2-1.0
Idle.2-2.0
626
2.0L
Ignition On.02
Idle.6-1.1
2.5L
Ignition OnLess Than 1
Idle1-2
(1) Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.
(1)Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.

MASS AIRFLOW (MAF) SENSOR VOLTAGE (EXCEPT B2500, B3000 & B4000)

THROTTLE POSITION SENSOR

Throttle Valve Position (Degrees) (1)(2) PID Voltage
Zero0.65
100.97
201.44
301.90
402.37
502.84
603.31
703.78
803.90
(1) TP sensor is not adjustable. (2) Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.
(1)TP sensor is not adjustable.
(2)Check sensor voltage using New Generation Star (49 T088 0A0) scan tool connected to Data Link Connector (DLC) 2. DLC is located under left side of instrument panel, right of steering column.

THROTTLE POSITION (TP) SENSOR VOLTAGE (B2500, B3000 & B4000)
