Body Computer Systems: Removal & Installation Mazda 626 GF

Body, Cab Control Systems 2 illustrations

Removal & Installation

Disconnect negative battery cable. Remove left side kick panel trim. Remove joint box mounting screws and remove joint box. Disconnect CPU electrical connectors. Separate CPU from joint box. To install, reverse removal procedure.

Body Computer System Wiring Diagram (Millenia). Scheme 2

Scheme 2: Body Computer System Wiring Diagram (Millenia)

Scheme 2: Body Computer System Wiring Diagram (Millenia)

Body Computer System Wiring Diagram (626). Scheme 3

Scheme 3: Body Computer System Wiring Diagram (626)

Scheme 3: Body Computer System Wiring Diagram (626)
