MAIN SWITCH
Check continuity across specified terminals of main switch connector with main switch button held in specified position. See appropriate MAIN SWITCH CONTINUITY TEST table. (Scheme 1)and (Scheme 2). Replace main switch if continuity is not as specified.
| Switch Position (1) | Terminals | |
|---|---|---|
| Driver | ||
| UP | A & L; H & J | |
| DOWN | A & J; H & L | |
| One-Touch DOWN | A & J; H & L | |
| Off (Neutral) | H, J & L | |
| Passenger | ||
| UP | A & D; B & H | |
| DOWN | A & B; D & H | |
| Off (Neutral) | B, D & H | |
| Right Rear | ||
| UP | A & E; C & H | |
| DOWN | A & C; E & H | |
| Off (Neutral) | C, E & H | |
| Left Rear | ||
| UP | A & K; H & I | |
| DOWN | A & I; H & K | |
| Off (Neutral) | H, I & K | |
| (1) Ensure power cut switch is in ON position. | ||
| (1) | Ensure power cut switch is in ON position. |
MAIN SWITCH CONTINUITY TEST
Scheme 1
Scheme 2
POWER CUT SWITCH
Check continuity across specified terminals of main switch connector with power cut switch button held in specified position. See POWER CUT SWITCH CONTINUITY TEST table. (Scheme 1)and (Scheme 2). Replace main switch if continuity is not as specified.
| Switch Position | Terminals (1) | Continuity | |
|---|---|---|---|
| Passenger | |||
| ON | B, D & H | Yes | |
| OFF | B & D | Yes | |
| Right Rear | |||
| ON | C, E & H | Yes | |
| OFF | C & E | Yes | |
| Left Rear | |||
| ON | H, I & K | Yes | |
| OFF | I & K | Yes | |
| (1) Main switch connector terminals. | |||
| (1) | Main switch connector terminals. |
POWER CUT SWITCH CONTINUITY TEST
SUB-SWITCH
Check continuity across specified terminals of sub-switch connector with main switch button held in specified position. See SUB-SWITCH CONTINUITY TEST table. (Scheme 3) Replace sub-switch if continuity is not as specified.
| Application & Switch Position | Continuity Between Terminals |
|---|---|
| UP | D & H; B & G |
| Off (Neutral) | A & B; D & H |
| DOWN | A & B; G & H |
SUB-SWITCH CONTINUITY TEST
Scheme 3
WINDOW MOTOR
Disconnect window motor connector. Apply battery voltage and ground across window motor connector terminals. Reverse polarity to move window in opposite direction. Replace window motor if it does not operate.
| WARNING | Window regulator is spring-loaded to assist window motor during upward movement. Before separating window motor from regulator, securely position regulator arms in full-up position (if possible). This will relieve spring pressure as much as possible, preventing injury when window motor is separated from regulator. |
