FUSE PANEL LOCATION
Main fuse block is located by battery in engine compartment and contains high amperage fuses which protect multiple circuits. Fuse box, located above driver's left knee and accessible through a removable cover, contains fuses for individual circuits.
Scheme 1
Fuse & Circuit Breaker Identification
- 1 - 15 Amp Brakelights, Horn
- 2 - 30 Amp Power Door Locks
- 3 - Empty
- 4 - 20 Amp Headlight Cleaners
- 5 - 15 Amp Engine
- 6 - Empty
- 7 - 20 Amp Cooling Fan
- 8 - 15 Amp Air Conditioner
- 9 - 15 Amp Interior Lights
- 10 - 10 Amp Taillights
- 11 - 10 Amp Meters
- 12 - 15 Amp Sun Roof
- 13 - 15 Amp Windshield Wipers
- 14 - 15 Amp Car Component Stereo
- 15 - 30 Amp Spare Fuse
- 16 - 15 Amp Spare Fuse
- 17 - 10 Amp Spare Fuse
- 18 - 30 Amp Power Windows
- 19 - 20 Amp Rear Window Defogger
- 20 - 15 Amp
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise warning that the pads need replacement.
HALOGEN BULBS
Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.
