Wiring diagram: Memory systems — Memory systems circuit Mazda 6 GJ facelift 2
All systems
- Air conditioning
- Anti-lock brakes
- Anti-theft
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.5l skyactiv
- Engine performance 2.5l turbo skyactiv
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems
- Navigation 6
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer
Memory systems circuit (1 of 2) Mazda 6 GJ facelift 2
Components on the diagram
Memory systems circuit (2 of 2) Mazda 6 GJ facelift 2
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
