Front wheel alignment
| Item | Specification | |||||
|---|---|---|---|---|---|---|
| Fuel gauge indication | Empty | 1/4 | 1/2 | 3/4 | Full | |
| Maximum steering angle [Tolerance ±3°] | Inner | 38°54' | ||||
| Outer | 32°36' | |||||
| Total toe-in | (mm {in}) | Tire: 2±4 {0.08±0.16}, Rim inner: 1±3 {0.04±0.12} | ||||
| (degree) | 0°10'±20' | |||||
| Caster angle (1) (Reference value) [Tolerance ±1°] | MZR 2.5 | 3°37' | 3°38' | 3°39' | 3°41' | 3°42' |
| MZI 3.7 V6 | 3°34' | 3°35' | 3°37' | 3°38' | 3°40' | |
| Camber angle (1) (Reference value) [Tolerance ±1°] | MZR 2.5 | 0°09' | 0°10' | 0°12' | 0°13' | 0°15' |
| MZI 3.7 V6 | 0°10' | 0°11' | 0°14' | 0°16' | ||
| Steering axis inclination (Reference value) [Tolerance ±1°] | MZR 2.5 | 6°31' | 6°32' | 6°34' | 6°36' | 6°37' |
| MZI 3.7 V6 | 6°32' | 6°33' | 6°38' | |||
| *1 Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position. (1) Difference between left and right must not exceed 1°30' . | ||||||
| (1) | Difference between left and right must not exceed 1°30' . |
Scheme 2
- Loosen the tie-rod end locknuts.
- Remove the steering gear boot clamp.
- Turn the tie rods. (Scheme 2): Turning Tie Rods Standard length L 15.7-22.7 mm {0.619-0.893 in}
- Turn the tie rods equally to provide the correct maximum steering angle.
- Tighten the tie-rod end locknuts. Tightening torque 69-98 N.m {7.1-9.9 kgf.m, 51-72 ft.lbf}
- Verify that the boot is not twisted, and install the boot clamp.
- Adjust the toe-in after adjusting the steering angle.
Total Toe-in Adjustment
- Center the steering wheel and confirm that the vehicle wheels/tires are pointing straight.
- Loosen the left and right tie-rod end locknuts and turn the tie-rods equally. Both tie rods are right threaded, so turning the right tie-rod toward the front of the vehicle and the left toward the rear increases toe-in. NOTE: Turning both tie-rods one complete turn changes toe-in by about 6 mm {0.24 in} (0°36') .
- Tighten the tie-rod end locknuts to the specified torque. Tightening torque 69-98 N.m {7.1-9.9 kgf.m, 51-72 ft.lbf}
- Verify that the boot is not twisted, and install the boot clamp.
Rear wheel alignment
| Item | Specification | |||||
|---|---|---|---|---|---|---|
| Fuel gauge indication | Empty | 1/4 | 1/2 | 3/4 | Full | |
| Total toe-in | (mm {in}) | Tire: 2±4 {0.08±0.16} Rim inner: 1±3 {0.04±0.12} | ||||
| (degree) | 0°10'±20' | |||||
| Camber angle (1) (Reference value) [Tolerance ±1°] | 0°48' | 0°50' | 0°53' | 0°55' | 0°57' | |
| Thrust angle [Tolerance ±0°48'] | 0° | |||||
| *1 Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position. (1) Difference between left and right must not exceed 1°30'. | ||||||
| (1) | Difference between left and right must not exceed 1°30'. |
Scheme 3
Scheme 4
Scheme 5
- Loosen the locknut of the lateral link. (Scheme 3): Loosening Locknut Of Lateral Link
- Adjust the toe-in turning the adjusting link. (Scheme 4): Adjusting Total Toe-In Total toe-in 2±4 mm {0.08±0.16 in} NOTE: Toe change amount: 0°21'/ one rotation
- Tighten the locknut. (Scheme 5): Tightening Locknut Tightening torque 61-98 N.m {6.3-9.9 kgf.m, 45-72 ft.lbf}
