Removal Mazda 6 GJ

Seats: Removal & Installation 2 illustrations ~130 words

Removal

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. If any of the following work is performed, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION ) Replacement with a new seat weight sensor Replacement with a new seat weight sensor control module Replacement with new passenger-side seat par Disassembly of the passenger-side seat If any of the following work is performed, perform the seat weight sensor inspection using the M-MDS. (See SEAT WEIGHT SENSOR INSPECTION ) Removal of the passenger-side seat Loosening and retightening of passenger-side seat fixing bolts

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait 1 min or more.
  3. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-581617-S37007315702013101400000).) Front seat side cover (See «FRONT SEAT SIDE COVER REMOVAL/INSTALLATION»(ref-581617-S28421367832013101400000).) Front seat back component (See «FRONT SEAT BACK COMPONENT REMOVAL/INSTALLATION»(ref-581617-S42206516692013101400000).) Front seat back trim (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-581617-S13999254322013101400000).) Front seat cushion trim (See «FRONT SEAT CUSHION TRIM REMOVAL/INSTALLATION»(ref-581617-S36605066872013101400000).)
  4. Peel off the seat warmer unit from the position of the arrow shown in the figure. (Scheme 70): Identifying Seat Warmer Unit Peel Off Position CAUTION: There is a possibility for it to become impossible to reused when seat pad are damaged. Carefully remove the seat warmer unit glued onto the seat pad. (Scheme 71): Seat Warmer Unit
