Oem Wiring System: Overview Mazda 6 GJ

Identifying Vehicle Identification Number Code. Scheme 1

VEHICLE IDENTIFICATION NUMBERS (VIN)

1YV HZ8BB*D5 M00001

1YV HZ8BH*D5 M00001

1YV HZ8CB*D5 M00001

1YV HZ8CH*D5 M00001

1YV HZ8DB*D5 M00001

1YV HZ8DH*D5 M00001

1YV HZ8EB*D5 M00001

1YV HZ8EH*D5 M00001

Scheme 2

1. This service information comprises the sections shown below. (Scheme 2): Example Of Wiring Diagrams

Scheme 3

1. This shows ground points of the harness. (Scheme 3): Example Of Ground Point Wiring Diagram

Scheme 4

1. These diagrams show the circuits for each system, from the power supply to the ground. The power supply side is on the upper part of the page, the ground side on the lower part. The diagrams describe circuits with the ignition switch off. Below is an explanation of the various points in the diagram. (Scheme 4): Example Of Power Door Lock System Circuit Diagram

Example Of S And Start System Wiring Diagram. Scheme 5

Scheme 6

1. The routing diagram shows where electrical components are on the system circuit diagram by call out line and connector symbols. (Scheme 6): Example Of Routing Diagram

ABBREVIATIONS USED IN THIS SERVICE INFORMATION

Scheme 7

Scheme 8

1. Before disconnecting connectors or removing electrical parts, disconnect the negative battery cable. (Scheme 7): Disconnecting Negative Battery Cables (Scheme 8): Prying Up Hook Of Clip Using Flathead Screwdriver

Scheme 9

Scheme 10

1. To remove the wiring harness from the clip in the engine room, pry up the hook of the clip using a flathead screwdriver. (Scheme 9): Caution For Disconnecting Connectors CAUTION: Do not remove the Harness protective tape. Otherwise, the wires could rub against the body, which could result in water penetration and electrical shorting. (Scheme 10): Caution For Removing Harness Protective Tape

Scheme 11

1. When disconnecting connector, grasp the connectors, not the wires.
2. Connectors can be disconnected by pressing or pulling the lock lever as shown. see scheme 15: Locking Connector
