Dynamic Stability Control System: Removal & Installation Mazda 6 GJ

Anti-Lock/traction Control 9 illustrations ~601 words

DSC HU/CM REMOVAL/INSTALLATION

CAUTIONWhen replacing the DSC HU/CM, the configuration procedure must be done before removing the DSC HU/CM. If the configuration is not completed before removing the DSC HU/CM, DSC will not work properly after installation of the DSC HU/CM. The internal parts of the DSC HU/CM could be damaged if dropped. Be careful not to drop the DSC HU/CM. Replace the DSC HU/CM if it is subjected to an impact.

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-581618-S04530744522013101400000).) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-581657-S30702990112013101400000).) Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-581618-S05610234842013101400000).) Cowl panel (See «COWL PANEL REMOVAL/INSTALLATION»(ref-581621-S42468753042013101400000).)
  2. Disconnect the brake pipes (master cylinder side). (See «MASTER CYLINDER REMOVAL/INSTALLATION»(ref-581625-S22485775802013101400000).)
  3. For the vehicles with MZI 3.7 V6, perform the following steps. Remove the power steering reserve tank component. (See «POWER STEERING OIL PUMP REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-581622-S32034916752013101400000).) Disconnect the OCV connector. (See «OIL CONTROL VALVE (OCV) REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-581682-S35459348242013101400000).) Disconnect the ignition coil connector. (See «IGNITION COIL REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-581671-S40527084762013101400000).) Disconnect the HO2S (RH) connector. (See «HEATED OXYGEN SENSOR (HO2S) REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-581669-S04593467262013101400000).) Disconnect the pressure switch connector. (See «POWER STEERING OIL PUMP REMOVAL/INSTALLATION [MZI 3.7 V6]»(ref-581622-S32034916752013101400000).) Disconnect the wiring harness from the wiring harness bracket as shown in the figure. (Scheme 31): Identifying Wiring Harness And Bracket Set the wiring harness out of the way.
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
  6. Add brake fluid, bleed the brakes, and inspect for leakage after the installation has been completed. (See «BRAKE FLUID AIR BLEEDING»(ref-581625-S05094041712013101400000).)
  7. Configurate the DSC HU/CM (only when replacing it). (See «DSC CONFIGURATION»(ref-581627-S21066048472013101400000).)
  8. Clear the DTCs from the memory. (See «ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)]»(ref-581612-S35041327492013101400000).) (Scheme 32): Identifying DSC HU/CM Components With Torque Specifications

Scheme 33

Scheme 33: Connector Removal Note
Scheme 33: Connector Removal Note
  1. Disconnect the connector in the order shown in the figure. (Scheme 33): Identifying DSC HU/CM Connector Disconnect Order CAUTION: If sand or other particles get into the connector, it may be difficult to remove. In order not to damage the connector, be careful not to use excessive force removing the connector.

Scheme 34

Scheme 34: Brake Pipe Removal Note
Scheme 34: Brake Pipe Removal Note
  1. Place an alignment mark on the brake pipe and DSC HU/CM. (Scheme 34): Identifying Alignment Mark On Brake Pipe And DSC HU/CM
  2. Affix protective tape to the connector to prevent brake fluid from entering.
  3. Remove the brake pipe.
  4. Adhere protective tape to the installation area of the DSC HU/CM brake pipe to prevent foreign material penetration.

Scheme 35

Scheme 35: DSC HU/CM Removal Note
Scheme 35: DSC HU/CM Removal Note
  1. Move the DSC HU/CM component towards the inner side of the vehicle.
  2. Loosen the bolt as shown in the figure. (Scheme 35): Identifying DSC HU/CM, Bracket And Bolt
  3. Move the DSC HU/CM as shown in the figure.
  4. Remove the DSC HU/CM from the DSC HU/CM Bracket.

Scheme 36

Scheme 36: DSC HU/CM Installation Note
Scheme 36: DSC HU/CM Installation Note
  1. Install the DSC HU/CM from the DSC HU/CM Bracket as shown in the figure. (Scheme 36): Identifying DSC HU/CM, Bracket And Bolt
  2. Tighten the bolt as shown in the figure. Tightening torque 4.3-6.5 N.m {44-66 kgf.cm, 39-57 in.lbf}

Scheme 37

Scheme 37: Brake Pipe Installation Note
Scheme 37: Brake Pipe Installation Note
  1. Align the marks made before removal and install the brake pipe into the DSC HU/CM referring to the figure. (Scheme 37): Aligning Brake Pipe Marks On DSC HU/CM

Scheme 38

Scheme 38: Connector Installation Note
Scheme 38: Connector Installation Note
  1. Connect the connector in the order shown in the figure. (Scheme 38): Identifying DSC HU/CM Connector Connection Order
  2. After connecting the connector, verify that the connector is completely locked.

Scheme 39

Scheme 39: DSC CONFIGURATION
Scheme 39: DSC CONFIGURATION
  1. Connect the M-MDS (IDS) to the DLC-2. (Scheme 39): Identifying DLC-2 Location
  2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Module Programming".
  3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "ABS".
  4. Perform the configuration according to the directions on the screen.
  5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. (See «ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)]»(ref-581612-S35041327492013101400000).)

Connector Removal Note

  1. Pull aside the mudguard and disconnect the connector.
