Conventional Brake System: Overview Mazda 6 GH рестайлинг

Mechanical - Hydraulic 1 illustration ~286 words

Scheme 1

Scheme 1: CONVENTIONAL BRAKE SYSTEM LOCATION INDEX
1Brake fluid (See «BRAKE FLUID INSPECTION».) (See «BRAKE FLUID AIR BLEEDING».)
2Power brake unit (See «POWER BRAKE UNIT INSPECTION».) (See «POWER BRAKE UNIT REMOVAL/INSTALLATION».)
3Brake pedal (See «BRAKE PEDAL INSPECTION».) (See «BRAKE PEDAL REMOVAL/INSTALLATION».)
4Brake switch (See «BRAKE SWITCH INSPECTION».)
5Rear brake (disc) (See «REAR BRAKE (DISC) INSPECTION».) (See «REAR BRAKE (DISC) REMOVAL/INSTALLATION».) (See «DISC PAD (REAR) REPLACEMENT».) (See «CALIPER (REAR) DISASSEMBLY/ASSEMBLY».)
6Front brake (disc) (See «FRONT BRAKE (DISC) INSPECTION».) (See «FRONT BRAKE (DISC) REMOVAL/INSTALLATION».) (See «DISC PAD (FRONT) REPLACEMENT».) (See «CALIPER (FRONT) DISASSEMBLY/ASSEMBLY».)
7Master cylinder (See «MASTER CYLINDER REMOVAL/INSTALLATION».) (See «BRAKE FLUID LEVEL SENSOR INSPECTION».)
8Vacuum line (See «VACUUM LINE INSPECTION».) (See «VACUUM HOSE REMOVAL/INSTALLATION».)

PARTS DESCRIPTION CHART

Non-servo operation inspection

  1. If the pedal force and fluid pressure correlation is within the specification with the engine stopped and a vacuum amount of 0 kPa {0 mmHg, 0 inHg} , the system is normal. Standard power brake unit non-servo operation STANDARD POWER BRAKE UNIT NON-SERVO OPERATION CHART Vacuum amount at 0 kPa {0 mmHg, 0 inHg} Pedal force Fluid pressure 200 N {20.4 kgf, 45.0 lbf} 390 kPa {3.98 kgf/cm 2 , 56.6 psi} or more

Servo operation inspection

  1. Start the engine and depress the brake pedal when the vacuum reaches 66.7 kPa {500 mmHg, 19.7 inHg} .
  2. At this time, apply the indicated pedal force and if the fluid pressure is within the specification, the unit is normal.

Standard power brake unit servo operation

Vacuum amount at 66.7 kPa {500 mmHg, 19.7 inHg}
Pedal forceFluid pressure
200 N {20.4 kgf, 45.0 lbf}8,450 kPa {86.16 kgf/cm 2 , 1,226 psi} or more

STANDARD POWER BRAKE UNIT SERVO OPERATION CHART

Description

  1. Steering wheel vibrates in the rotation direction. The characteristic is most noticeable when applying brakes at a vehicle speed of 100-140 km/h {62.2-86.3 mph}.
  2. When applying the brakes, the vehicle body shakes back and forth. The seriousness of the shaking is not influenced by vehicle speed.
  3. When applying brakes, a pulsating force tries to push the brake pad back. The pulsation is transmitted to the brake pedal.
  1. Steering wheel vibrates in the rotation direction. This characteristic is most noticeable when applying brakes at a vehicle speed of 100-140 km/h {62.2-86.9 mph} .
  2. When applying the brakes, the vehicle body shakes back and forth. The seriousness of the shaking is not influenced by vehicle speed.
  3. When applying brakes, a pulsating force tries to push the brake pad back. The pulsation is transmitted to the brake pedal.
