IGNITION COIL REMOVAL/INSTALLATION [MZR 2.5]
- Disconnect the negative battery cable.
- Remove the plug hole plate. (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [MZR 2.5]»(ref-448577-S27590243452012012000000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
| 1 | Plug hole plate bracket |
|---|---|
| 2 | Connector |
| 3 | Ignition coil |
PARTS REFERENCE CHART
Scheme 4
SPARK PLUG REMOVAL/INSTALLATION [MZR 2.5]
| CAUTION | If a spark plug that is not as specified is installed, engine performance will be deteriorated. Install only the specified spark plug when replacing. |
- Disconnect the negative battery cable.
- Remove the plug hole plate. (See «PLUG HOLE PLATE REMOVAL/INSTALLATION [MZR 2.5]»(ref-448577-S27590243452012012000000) .)
- Remove the ignition coils. (See «IGNITION COIL REMOVAL/INSTALLATION [MZR 2.5]»(ref-448583-S42939397092012012000000) .)
- Remove the spark plugs using a plug-wrench.
- Install in the reverse order of removal.
Tightening torque
10-14 N.m {102-142 kgf.cm, 89-123 in.lbf}
