Security System and Locks System: Overview Mazda 6 GH рестайлинг

Door Locks & Anti-Theft Systems 18 illustrations ~377 words

Scheme 31

Scheme 31: Locks and Openers
Scheme 31: Locks and Openers
1Inner handle (See INNER HANDLE REMOVAL/INSTALLATION .) (See DOOR LOCK SWITCH REMOVAL/INSTALLATION .) (See DOOR LOCK SWITCH INSPECTION .)
2Hood release lever (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION .)
3Front door key cylinder (See FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION .)
4Front outer handle (See FRONT OUTER HANDLE REMOVAL/INSTALLATION .)
5Hood release cable (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION .)
6Hood latch (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION .)
7Fuel-filler lid opener lever (See FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION .)
8Fuel-filler lid opener cable (See FUEL-FILLER LID OPENER CABLE REMOVAL/INSTALLATION .)
9Trunk lid lock striker (See TRUNK LID LOCK STRIKER REMOVAL/INSTALLATION .)
10Trunk lid latch and release actuator (See TRUNK LID LATCH AND RELEASE ACTUATOR REMOVAL/INSTALLATION .) (See TRUNK LID LATCH AND RELEASE ACTUATOR INSPECTION .) (See TRUNK LID LATCH SWITCH INSPECTION .) (See TRUNK LID RELEASE ACTUATOR INSPECTION .) (See TRUNK LID LATCH MANUAL RELEASE PROCEDURE .)
11Fuel-filler lid opener (See FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION .)
12Rear door latch and lock actuator (See REAR DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION .) (See REAR DOOR LATCH AND LOCK ACTUATOR INSPECTION .) (See REAR DOOR LOCK ACTUATOR INSPECTION .) (See REAR DOOR LATCH SWITCH INSPECTION .)
13Rear outer handle (See REAR OUTER HANDLE REMOVAL/INSTALLATION .)
14Door lock striker (See DOOR LOCK STRIKER REMOVAL/INSTALLATION .)
15Front door latch and lock actuator (See FRONT DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION .) (See FRONT DOOR LATCH AND LOCK ACTUATOR INSPECTION .) (See FRONT DOOR LATCH SWITCH INSPECTION .) (See FRONT DOOR LOCK ACTUATOR INSPECTION .) (See DOOR LOCK-LINK SWITCH INSPECTION .) (See FRONT DOOR KEY CYLINDER SWITCH INSPECTION .)

PARTS DESCRIPTION CHART

Scheme 32

Scheme 32: Advanced Keyless Entry And Push Button Start System/Immobilizer System
Scheme 32: Advanced Keyless Entry And Push Button Start System/Immobilizer System
1Keyless beeper (See KEYLESS BEEPER REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See KEYLESS BEEPER INSPECTION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
2Keyless antenna (See KEYLESS ANTENNA REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) Touch sensor (See TOUCH SENSOR REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
3Request switch (See REQUEST SWITCH REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See REQUEST SWITCH INSPECTION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
4Trunk lid opener switch (See TRUNK LID OPENER SWITCH REMOVAL/INSTALLATION .) (See TRUNK LID OPENER SWITCH INSPECTION .)
5Advanced key (See ADVANCED KEY ID CODE REGISTRATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See CLEARING ADVANCED KEY [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See ADVANCED KEY BATTERY REPLACEMENT [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
6Coil antenna (See COIL ANTENNA REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
7Keyless control module (See KEYLESS CONTROL MODULE REMOVAL/INSTALLATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See KEYLESS CONTROL MODULE INSPECTION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See STEERING LOCK UNIT ID CODE REGISTRATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See KEYLESS CONTROL MODULE CONFIGURATION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .) (See PERSONALIZATION FEATURES SETTING PROCEDURE .) (See IMMOBILIZER SYSTEM-RELATED PARTS PROGRAMMING [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)
8Keyless receiver (See KEYLESS RECEIVER INSPECTION [KEYLESS ENTRY SYSTEM] .) (See KEYLESS RECEIVER INSPECTION [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] .)

PARTS DESCRIPTION CHART

Scheme 33

Scheme 33: Keyless Entry System/Immobilizer System
Scheme 33: Keyless Entry System/Immobilizer System
1Coil antenna (See COIL ANTENNA REMOVAL/INSTALLATION [KEYLESS ENTRY SYSTEM] .)
2Transmitter (See TRANSMITTER BATTERY REPLACEMENT [KEYLESS ENTRY SYSTEM] .) (See TRANSMITTER ID CODE REGISTRATION [KEYLESS ENTRY SYSTEM] .)
3Keyless receiver (See KEYLESS RECEIVER REMOVAL/INSTALLATION .) (See KEYLESS RECEIVER INSPECTION [KEYLESS ENTRY SYSTEM] .)

PARTS DESCRIPTION CHART

Scheme 34

Scheme 34: FRONT OUTER HANDLE REMOVAL/INSTALLATION
Scheme 34: FRONT OUTER HANDLE REMOVAL/INSTALLATION

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}.
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-448656-S34800399052012012000000) .) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-448591-S04868612742012012000000) .) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-448571-S41149988882012012000000) .) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-448692-S06652197342012012000000) .) Front door key cylinder (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION»(ref-448614-S11884518702012012000000) .)
  4. Disconnect the keyless antenna connector (With advanced keyless entry and push button start system).
  5. Remove the front outer handle.
  6. Remove the screw. NOTE: The screw cannot be removed because of the stopper.
  7. Press down the rod holder in the direction of arrow (1) and remove the front outer handle bracket in the direction of arrow (2).
  8. Install in the reverse order of removal.

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39: REAR OUTER HANDLE REMOVAL/INSTALLATION
Scheme 39: REAR OUTER HANDLE REMOVAL/INSTALLATION

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. Fully close the rear door glass.
  2. Disconnect the negative battery cable.
  3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-448656-S20049256112012012000000) .)
  4. Remove the hole cover.
  5. Remove the service hole cover.
  6. Remove the screw from the service hole. NOTE: The screw cannot be removed because of the stopper.
  7. Press the tab on the rear outer handle bracket in the direction of the arrow.
  8. Maintaining the condition in procedure 7, remove the outer handle garnish.
  9. Remove the rear outer handle.
  10. Loosen the screw.
  11. Press down the rod holder in the direction of arrow (1) and remove the rear outer handle bracket in the direction of arrow (2).
  12. Install in the reverse order of removal.

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47: Front Inner Handle
Scheme 47: Front Inner Handle
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-448656-S34800399052012012000000) .)
  4. Disconnect the door lock switch connector.
  5. Disconnect each cable and remove the front inner handle.
  6. Install in the reverse order of removal.

Scheme 48

Scheme 48
Scheme 48
