Engine Cooling System [Mzi 3.7 V6]: Overview Mazda 6 GH рестайлинг

Cooling System (Mechanical) 1 illustration

Scheme 21

Scheme 21: COOLING SYSTEM LOCATION INDEX [MZI 3.7 V6]

Scheme 21: COOLING SYSTEM LOCATION INDEX [MZI 3.7 V6]

1	Thermostat (See THERMOSTAT REMOVAL/INSTALLATION [MZI 3.7 V6] .) (See THERMOSTAT INSPECTION [MZI 3.7 V6] .)
2	Cooling system cap (See COOLING SYSTEM CAP INSPECTION [MZI 3.7 V6] .)
3	Coolant reserve tank (See ENGINE COOLANT LEVEL INSPECTION [MZI 3.7 V6] .) (See COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI 3.7 V6] .)
4	Cooling fan motor No. 2 (See COOLING FAN MOTOR REMOVAL/INSTALLATION [MZI 3.7 V6] .) (See COOLING FAN MOTOR INSPECTION [MZI 3.7 V6] .)
5	Fan control module (See FAN CONTROL MODULE INSPECTION [MZI 3.7 V6] .)
6	Cooling fan motor No. 1 (See COOLING FAN MOTOR REMOVAL/INSTALLATION [MZI 3.7 V6] .) (See COOLING FAN MOTOR INSPECTION [MZI 3.7 V6] .)
7	Radiator (See ENGINE COOLANT PROTECTION INSPECTION [MZI 3.7 V6] .) (See ENGINE COOLANT REPLACEMENT [MZI 3.7 V6] .) (See ENGINE COOLANT LEAKAGE INSPECTION [MZI 3.7 V6] .) (See RADIATOR REMOVAL/INSTALLATION [MZI 3.7 V6] .)
8	Water pump (See WATER PUMP REMOVAL/INSTALLATION [MZI 3.7 V6] .)

COOLING SYSTEM COMPONENTS REFERENCE CHART
