Pattern 1
- Terminal: 8G (+) <--> body ground (-)
- Oscilloscope setting: 2 V/DIV (Y), 1 ms/DIV (X), DC range
Scheme 54
Scheme 55
- Terminal
- Bonnet latch switch signal: 1S (+) <--> body ground (-)
- Front door latch switch (driver side) input signal: 8B (+) <--> body ground (-)
- Lock/unlock input: 8C (+) <--> body ground (-)
- Front door latch switch (passenger side) signal: 8D (+) <--> body ground (-)
- Unlock input (Driver-side door lock-link switch): 8E (+) <--> body ground (-)
- Rear door switch (RH) signal: 8F (+) <--> body ground (-)
- Lock input (Driver-side door lock-link switch): 8G (+) <--> body ground (-)
- Rear door switch (LH) signal: 8H (+) <--> body ground (-)
- Oscilloscope setting: 1 V/DIV (Y), 1 ms/DIV (X), DC range
Pattern 3
- Terminal: 5F (+) <--> body ground (-)
- Oscilloscope setting: 1 V/DIV (Y), 200μs/DIV (X), DC range
Scheme 56
Scheme 57
- Terminal: Interior light control: 6M (+) <--> body ground (-) Courtesy light control: 6O (+) <--> body ground (-) Trunk room light control: 7B (+) <--> body ground (-)
- Oscilloscope setting: 5 V/DIV (Y), 5 ms/DIV (X), DC range
BODY CONTROL MODULE (BCM) CONFIGURATION
Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the BCM CONFIGURATION.
- Connect the M-MDS to DLC-2.
- Perform the configuration according to the directions on the screen.
- Retrieve DTCs by the M-MDS, then verify that there is no DTC present.
- If a DTC(s) is detected, perform the applicable DTC inspection. (See «DTC TABLE [BCM]»(ref-448639-S11598983262012012000000) .)
Scheme 58
CONTROL SYSTEM PERSONALIZATION FEATURES SETTING PROCEDURE
Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the PERSONALIZATION FEATURES SETTING PROCEDURE.
- Connect the M-MDS to the DLC-2.
- After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select the "Module Programming". Select menu in the "BCM/GEM".
- Select an item name, and then select option.
Scheme 59
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Smart turn | The 'turn light system' function can be set. | Disabled | Disabled/Enabled | BCM |
| 2 stage door unlocking (with AKE) | 2-step unlocking system can be set. | Enabled | Disabled/Enabled | BCM |
| Auto room lamp (when doors unlocked) | The automatic illumination function of the interior light when the doors are locked can be canceled. | Enabled | Disabled/Enabled | BCM |
| Auto relock timer (without AKE) | Auto re-lock operation timing can be changed. | 30sec | Disabled, 30sec, 60sec, 90sec | BCM |
| Auto room lamp (when IG-Off) | The automatic illumination function of the interior light after the ignition is switched off can be canceled. | Enabled | Disabled/Enabled | BCM |
| Answer Back Buzzer | Answer back buzzer can be set to inoperable. | Enabled | Disabled/Enabled | BCM |
| Window closing/opening with advanced-key/transmitter | Exterior open/close function can be set to inoperable. | Enabled | Disabled/Enabled | BCM |
| Room lamp timer | The elapsed time between the doors closing and the interior light turning off can be adjusted. | 15sec | 15sec, 7.5sec, 30sec, 60sec | BCM |
| Room Lamp Battery Saver Timer | The elapsed time for the interior light to automatically turn off when a door is ajar can be adjusted. | 30min | 30min/10min | BCM |
| Window closing with key | Exterior close function can be set to inoperable. | Enabled | Disabled/Enabled | BCM |
| Window opening with key | Exterior open function can be set to inoperable. | Enable | Disabled/Enabled | BCM |
CONTROL SYSTEM PERSONALIZATION FEATURES SETTING REFERENCE CHART
