Front Axle: Overview Mazda 6 GG рестайлинг

Scheme 1

Scheme 2

1. Position a dial indicator against the wheel hub.
2. Push and pull the wheel hub by hand in the axial direction and measure the wheel bearing play. Maximum front wheel bearing play 0.05 mm {0.002 in}
3. If the bearing play exceeds the specification, replace and tighten the locknut to the specified torque and retest. Replace the wheel bearing as necessary.

Scheme 3

Scheme 4

1. Remove the hub bolt using the SSTs. NOTE: If the dust cover interferes with the wheel hub bolt and the wheel hub bolt cannot be removed, tap the part shown in the figure with a chisel lightly and bend the processing point back to the steering knuckle side.
2. Install the hub bolt into the wheel hub and install a washer and hub nut on the hub bolt.
3. Tighten the hub nut while holding the wheel hub using a brass bar.
