COMBINATION SWITCH DISASSEMBLY/ASSEMBLY
| CAUTION | The clock spring is generally not to be removed from the combination switch as may result in a malfunction of the steering angle sensor. However, remove it only when replacing the clock spring as a single unit by referring to CLOCK SPRING REMOVAL/INSTALLATION. (See CLOCK SPRING REMOVAL/INSTALLATION. ) |
Scheme 84
- Disassemble in the order indicated in the table.
- Assemble in the reverse order of disassembly.
Scheme 85
Scheme 85: STEERING ANGLE SENSOR INSPECTION
- Disconnect the steering angle sensor connector.
- Connect battery positive voltage to terminal A and ground to terminal F of the steering angle sensor.
- Turn the steering wheel to the right and left, and verify that the voltage and pulses at the terminals are as shown in the figure. If there is any malfunction, replace the body of the combination switch.
Scheme 86
Scheme 86: LIGHT SWITCH REMOVAL/INSTALLATION
- Disconnect the negative battery cable.
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION.»(ref-244641-S13048422602006092500000) )
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
