Starting System (L3, Aj): Removal & Installation Mazda 6 GG рестайлинг

Starter 3 illustrations ~137 words

STARTER REMOVAL/INSTALLATION [L3, AJ]

WARNINGWhen the battery cables are connected, touching the vehicle body with starter terminal B generates sparks. This cap cause personal injury, fire, and damage to the electrical components. Always disconnect the battery before performing the following operation.

Scheme 19

Scheme 19: L3
Scheme 19: L3
  1. Disconnect the negative battery cable.
  2. Remove the air cleaner. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-244570-S29535323642006092500000) ).
  3. Remove the under cover.
  4. Remove the clutch release cylinder with the pipes still connected. (MTX) (See «CLUTCH RELEASE CYLINDER REMOVAL/INSTALLATION [G35M-R, A65M-R]»(ref-244595-S27480505652006092500000) ).
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal.

Scheme 20

Scheme 20: AJ
Scheme 20: AJ

Scheme 21

Scheme 21
Scheme 21
  1. Remove the battery and the battery tray. (See «BATTERY REMOVAL/INSTALLATION [L3, AJ]»(ref-244569-S13769513152006092500000) ).
  2. Remove the air cleaner. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
  3. Disconnect the selector cable and the selector cable bracket. (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-244612-S18640681322006092500000) ). (ATX)
  4. Position the harness bracket out of the way. (ATX)
  5. Remove in the order indicated in the table. MTX ATX
  6. Install in the reverse order of removal.
