Interior Trim: Removal & Installation Mazda 6 GG рестайлинг

HEADLINER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: Microphone (vehicles with car-navigation system). See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244641-S06297457352006092500000) ). Upper anchor of the front seat belt. See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S13812292832006092500000) ). Rear scuff plate. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S40068604252006092500000) ). B-pillar lower trims. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244641-S32266021582006092500000) ). B-pillar upper trims. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-244641-S01884535062006092500000) ). C-pillar trims. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244641-S20872849472006092500000) ). D-pillar trims (Sport Wagon). See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON]»(ref-244641-S02026422192006092500000) ). Front and rear map lights. See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light. See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-244641-S23073448042006092500000) ).
6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-244641-S31883545592006092500000) ).
7. Remove the net anchor. (Sport Wagon)
8. Disconnect the roof harness connector, remove the clip, and remove the connector.
9. Disconnect the rear washer hose. (5-Door, Sport Wagon)
10. Place the rear center seat belt bezel out of the way of the headliner. (Sport Wagon)
11. Remove the fasteners.
12. Remove the retainer holding the roof panel and remove the headliner.

Scheme 80

Scheme 81

1. 13. Take the headliner off from the passenger-side door opening. (Sport Sedan, 5-Door)
2. 14. Take the headliner off from the liftgate opening. (Sport Wagon)
3. 15. Install in the reverse order of removal.

Scheme 82

Scheme 83

1. Remove the screw, then the sunvisor.
2. Disconnect the vanity mirror illumination connector.
3. Disengage the center adapter (sunvisor stopper) from the body using a fastener remover.
4. Install in the reverse order of removal.

Scheme 84

Scheme 85

1. Insert a screwdriver into the assist handle notch and remove the assist handle cover.
2. Pull the assist handle outward, then remove the assist handle.
3. Install in the reverse order of removal.

Scheme 86

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the following parts: Microphone (vehicles with car-navigation system). See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims. See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244641-S06297457352006092500000) ). Upper anchor of the front seat belt. See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S13812292832006092500000) ). Rear scuff plate. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S40068604252006092500000) ). B-pillar lower trims. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244641-S32266021582006092500000) ). B-pillar upper trims. See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-244641-S01884535062006092500000) ). C-pillar trims. See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244641-S20872849472006092500000) ). D-pillar trims (Sport Wagon). See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON]»(ref-244641-S02026422192006092500000) ). Front and rear map lights. See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light. See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-244641-S23073448042006092500000) ).
6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-244641-S31883545592006092500000) ).
7. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-244641-S23816200972006092500000) ).
8. Remove the fasteners.
9. Pull the shock absorbing pad, then disengage the clip A or B from the body.
10. Install in the reverse order of removal.

Scheme 87

1. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S40068604252006092500000) ).
2. Remove the tire house trim. (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-244641-S23548003552006092500000) ).
3. Remove the trunk side upper trim. (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON]»(ref-244641-S11561729072006092500000) ).
4. Remove the screws.
5. Remove the tonneau cover anchor.
6. Install in the reverse order of removal.

Scheme 88

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seats. See «FRONT SEAT REMOVAL/INSTALLATION [L3 WITH TC].»(ref-244642-S36408855162006092500000) ) (See «FRONT SEAT REMOVAL/INSTALLATION [EXCEPT L3 WITH TC].»(ref-244642-S08168236352006092500000) ) Rear seat. See «REAR SEAT REMOVAL/INSTALLATION [SPORT SEDAN].»(ref-244642-S09581292042006092500000) ). See «REAR SEAT REMOVAL/INSTALLATION [MAZDASPEED6].»(ref-244642-S37428177062006092500000) ) (See «REAR SEAT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244642-S05768026702006092500000) ) Car-navigation unit (vehicles with car-navigation system). See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION.»(ref-244657-S37173007562006092500000) ) Audio amplifier (BOSE). See «AUDIO AMPLIFIER REMOVAL/INSTALLATION.»(ref-244657-S18652260402006092500000) ) Front scuff plates. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S13812292832006092500000) ). Rear scuff plates. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244641-S40068604252006092500000) ). Console. See «CONSOLE REMOVAL/INSTALLATION»(ref-244641-S30388317692006092500000) ). Front side trims. See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244641-S37496168562006092500000) ). B-pillar lower trims. See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244641-S32266021582006092500000) ). Lower anchor of the front seat belt installation bolts. See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Tire house trims (5-Door, Sport Wagon). See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-244641-S23548003552006092500000) ).
3. Remove the fuel-filler lid opener bezel.
4. Remove the fasteners.
5. Remove the cap nuts.
6. Remove the clips.
7. Take the floor covering off from the front passenger-side door opening.
8. Install in the reverse order of removal.
