Differential: Overview Mazda 6 GG рестайлинг

Scheme 31

Scheme 32

1. Place the vehicle on level ground.
2. Remove the filler plug and washer.
3. Verify that the oil is at the brim of the filler plug hole.
4. If it is low, add the specified oil.
5. Install a new washer and the filler plug, and tighten. Tightening torque 39.2-53.9 N.m {4.0-5.4 kgf.m, 29.0-39.7 ft.lbf}

Scheme 33

1. Place the vehicle on level ground.
2. Remove the filler plug.
3. Remove the drain plug and drain the differential oil into a container.
4. Install a new washer and the drain plug, and tighten. Tightening torque 39.2-53.9 N.m {4.0-5.4 kgf.m, 29.0-39.7 ft.lbf}
5. Add the specified differential oil from the filler plug until the level reaches the brim of the plug hole. Rear differential oil type Grade: API service GL-5 Viscosity: SAE90, SAE 80W-90 SAE 75W-90 (Not available from Mazda) Rear differential oil capacity (approximate quantity) 1.00 L {1.06 US qt, 0.88 Imp qt}
6. After filling with differential oil, perform oil level inspection.
7. Install a new washer and the drain plug, and tighten. Tightening torque 39.2-53.9 N.m {4.0-5.4 kgf.m, 29.0-39.7 ft.lbf}
