Lubrication: Removal & Installation Mazda 6 GG

Lubrication System 27 illustrations ~1451 words

ENGINE OIL REPLACEMENT

WARNINGHot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIn case you spill the engine oil on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.

Scheme 3

Scheme 3

Scheme 4

Scheme 4
  1. Position the vehicle on level ground.
  2. Remove the oil filler cap.
  3. Remove the under cover.
  4. Remove the oil pan drain plug.
  5. Drain the engine oil into a container.
  6. Inspect the rubber seal of the oil pan drain plug and make sure there are no cracks or damage. If necessary, replace the oil pan drain plug.
  7. Clean the flange surface (seal rubber) on the oil pan drain plug, then install the oil pan drain plug. Tightening torque 22-30 N.m {2.2-3.0 kgf.m, 16.3-21.6 ft.lbf} NOTE: The amount of residual oil in the engine can vary according to the replacement method, oil temperature, etc. Verify the oil level after engine oil replacement.
  8. Refill the engine oil with the specified type and amount, then install the oil filler cap. Oil capacity Recommended engine oil
  9. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  10. Inspect the oil level. If necessary, add oil. (See «ENGINE OIL LEVEL INSPECTION»(ref-193832-S28277649722005092600000) .)
  11. Install the under cover.

L3

WARNINGContinuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil. Hot engines and the engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled.

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. Remove the under cover.
  2. Remove the oil pressure switch.
  3. Screw the SSTs into the oil pressure switch installation hole.
  4. Warm up the engine to normal operating temperature.
  5. Run the engine at the specified speed, and note the gauge readings. If the pressure is not as specified, inspect for the cause and repair or replace as necessary. NOTE: The oil pressure can vary with oil viscosity and temperature. Oil pressure 395-649 kPa {4.03-6.61 kgf/cm2, 57.3-94.1 psi} [3,000 rpm]
  6. Stop the engine and wait until it is cool.
  7. Remove the SSTs.
  8. Apply silicone sealant to the oil pressure switch threads (Scheme 6)
  9. Install the oil pressure switch. Tightening torque 12-16 N.m {1.2-1.7 kgf.m, 9-12 ft.lbf}
  10. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  11. Install the under cover.

AJ

WARNINGContinuous exposure to USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil. Hot engines and the engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled.

Scheme 7

Scheme 7

Scheme 8

Scheme 8
  1. Remove the under cover.
  2. Remove the drive belt. (See «DRIVE BELT REPLACEMENT [AJ]»(ref-193831-S07100492352005092600000).)
  3. Remove the A/C compressor with the pipe still connected. Position the A/C compressor so that it is out of the way. (See «A/C COMPRESSOR REMOVAL/INSTALLATION»(ref-193872-S35734844182005092600000).)
  4. Remove the oil pressure switch.
  5. Screw the SSTs into the oil pressure switch installation hole.
  6. Install the A/C compressor. (See «A/C COMPRESSOR REMOVAL/INSTALLATION»(ref-193872-S35734844182005092600000).)
  7. Install the drive belt. (See «DRIVE BELT REPLACEMENT [AJ]»(ref-193831-S07100492352005092600000).)
  8. Warm up the engine to normal operating temperature.
  9. Run the engine at the specified speed, and note the gauge readings. If the pressure is not as specified, inspect for the cause and repair or replace as necessary. NOTE: The oil pressure can vary with oil viscosity and temperature. Oil pressure 138-310 kPa {1.40-3.17 kgf/cm2, 20-45 psi} [1,500rpm]
  10. Stop the engine and wait until it is cool.
  11. Remove the drive belt. (See «DRIVE BELT REPLACEMENT [AJ]»(ref-193831-S07100492352005092600000).)
  12. Remove the A/C compressor with the pipe still connected. Position the A/C compressor so that it is out of the way. (See «A/C COMPRESSOR REMOVAL/INSTALLATION»(ref-193872-S35734844182005092600000).)
  13. Remove the SSTs.
  14. Apply silicone sealant to the oil pressure switch threads (Scheme 8)
  15. Install the oil pressure switch. Tightening torque 12-16 N.m {1.2-1.7 kgf.m, 9-12 ft.lbf}
  16. Install the A/C compressor. (See «A/C COMPRESSOR REMOVAL/INSTALLATION»(ref-193872-S35734844182005092600000).)
  17. Install the drive belt. (See «DRIVE BELT REPLACEMENT [AJ]»(ref-193831-S07100492352005092600000).)
  18. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  19. Install the under cover.

OIL FILTER REPLACEMENT

WARNINGContinuous exposure with USED engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after this work. Hot engines and engine oil can cause severe burns. Turn off the engine and wait until it and the engine oil have cooled.
CAUTIONTo avoid damage to the oil filter, use only specified oil filter.

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. Remove the under cover.
  2. Loosen the oil filter drain plug. (Do not remove.)
  3. Loosen the filter cover for 1 turn using a commercially available, cup-type oil filter wrench ( diameter- 75.6 mm {3.0 in}, 14 sided ).
  4. Remove the oil filter drain plug, and drain the engine oil. NOTE: Oil could be easily drained when the air is in the filter.
  5. Loosen the oil filter cover for another 1 turn.
  6. Remove the oil filter cover and the oil filter.
  7. Use a clean rag to wipe off the mounting surface on the oil filter adapter and the oil filter cover.
  8. Apply clean oil to a new O-ring of a new oil filter and a new oil filter drain plug.
  9. Install the oil filter, oil filter drain plug, and oil filter cover.
  10. Tighten the oil filter cover and the oil filter drain plug. Tightening torque Oil filter cover: 30-35 N.m {3.1-3.5 kgf.m, 22.2-25.8 ft.lbf} Oil filter drain plug: 9-10 N.m {91.8-101.9 kgf.cm, 79.6-88.4 in.lbf}
  11. Start the engine and inspect for oil leakage.
  12. Inspect the oil level. If necessary, add oil. (See «ENGINE OIL LEVEL INSPECTION»(ref-193832-S28277649722005092600000) .)
  13. Install the under cover.

Scheme 11

Scheme 11: AJ
  1. Remove the under cover.
  2. Remove the oil filter from above using a filter wrench.
  3. Use a clean rag to wipe off the mounting surface.
  4. Apply clean engine oil to the O-ring of new oil filter.
  5. Install the oil filter until the O-ring contacts the sealing surface.
  6. Tighten the filter 3/4 turns by hand. CAUTION: In case you spill engine oil on the exhaust system or the engine, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.
  7. Start the engine and inspect for oil leakage.
  8. Inspect the oil level. Add oil if necessary. (See «ENGINE OIL LEVEL INSPECTION»(ref-193832-S28277649722005092600000) .)
  9. Install the under cover.

Scheme 12

Scheme 12: L3
  1. Disconnect the negative battery cable.
  2. Remove the under cover.
  3. Drain the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  4. Remove the engine front cover. (See «TIMING CHAIN REMOVAL/INSTALLATION [L3]»(ref-193830-S39231487502005092600000).)
  5. Remove in the order indicated in the (Scheme 12).
  6. Install in the reverse order of removal.
  7. Refill the engine oil with the specified type and amount. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  8. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  9. Inspect the oil level. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)

Scheme 13

Scheme 13: Oil Pan Installation Note (L3)

Scheme 14

Scheme 14

Scheme 15

Scheme 15
  1. Use a square ruler to align the junction of the oil pan and the cylinder block on the engine front cover side.
  2. Apply silicone sealant to the oil pan along the inside of the bolt holes.
  3. Tighten the bolts in the order (Scheme 15)

Scheme 16

Scheme 16: AJ
  1. Disconnect the negative battery cable.
  2. Remove the under cover.
  3. Drain the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  4. Remove the TWC (RH). (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-193835-S39423833602005092600000).)
  5. Remove in the order indicated in (Scheme 16).
  6. Install in the reverse order of removal.
  7. Refill the engine oil with the specified type and amount. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  8. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  9. Inspect the oil level. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)

Scheme 17

Scheme 17: Oil Pan Removal Note (AJ)

Scheme 18

Scheme 18
  1. Remove the transaxle housing bolts from oil pan.
  2. Loosen the oil pan bolts and studs in two or three passes in the order (Scheme 18)

Scheme 19

Scheme 19: Oil Pan Gasket Installation Note (AJ)
  1. Apply silicone sealant to the cylinder block (Scheme 19) Dot diameter 10 mm {0.39 in}

Scheme 20

Scheme 20: Oil Pan Installation Note (AJ)

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. Install the oil pan bolts and studs (Scheme 20)
  2. Tighten the transaxle housing bolts to oil pan.
  3. Tighten the oil pan bolts and studs in several passes in the order (Scheme 22)

Scheme 23

Scheme 23: L3
  1. Disconnect the negative battery cable.
  2. Remove the under cover.
  3. Remove the oil pan. (See «OIL PAN REMOVAL/INSTALLATION»(ref-193832-S19439408322005092600000).
  4. Remove in the order indicated in (Scheme 23).
  5. Install in the reverse order of removal.
  6. Start the engine and inspect for oil leakage. If the oil leaks, specified the faulty part and repair or replace it.
  7. Inspect the oil level. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  8. Inspect the oil pressure. (See «OIL PRESSURE INSPECTION»(ref-193832-S28990393082005092600000).)
  9. Install the under cover.

Scheme 24

Scheme 24: Oil Pump Sprocket Removal/Installation Note (L3)
  1. Install the SST to the oil pump sprocket to stop the oil pump from rotating.

Scheme 25

Scheme 25: Oil Pump Installation Note (L3)
  1. Tighten the oil pump bolts in two steps in the order indicated in (Scheme 25). Tightening torque: 1)8-10N.m {81.6-101.9 kgf.cm, 70.9-88.4 in.lbf} 2) 20-25 N.m {2.1-2.5 kgf.m, 15.2-18.4 ft.lbf}

Scheme 26

Scheme 26: AJ
  1. Disconnect the negative battery cable.
  2. Remove the under cover.
  3. Remove the oil pan. (See «OIL PAN REMOVAL/INSTALLATION»(ref-193832-S19439408322005092600000).)
  4. Remove the timing chain. (See TIMING CHAIN REMOVAL/INSTALLATION) [AJ].)
  5. Remove in the order indicated in (Scheme 26).
  6. Install in the reverse order of removal.
  7. Start the engine and inspect for oil leakage. If the oil leaks, specified the faulty part and repair or replace it.
  8. Inspect the oil level. (See «ENGINE OIL REPLACEMENT»(ref-193832-S31062078502005092600000).)
  9. Inspect the oil pressure. (See «OIL PRESSURE INSPECTION»(ref-193832-S28990393082005092600000).)

Scheme 27

Scheme 27: Oil Pump Removal Note (AJ)
  1. Loosen the oil pump bolts in the order (Scheme 27)

Scheme 28

Scheme 28: Oil Pump Installation Note (AJ)
  1. Tighten the oil pump bolts in the order (Scheme 28)

Scheme 29

Scheme 29: Oil Strainer Installation Note (AJ)
  1. Tighten the oil strainer bolts. Tightening torque 8-12 N.m {82-122 kgf.cm, 71-106 in.lbf}
  2. Tighten the oil strainer stay nut to 15.0 N.m {153 kgf.cm, 133 in.lbf} , then tighten it further 45° using the SST .
