TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Front seat mounting bolts | 27-39 (37-53) | |
| Seat belt | ||
| Anchor bolts | 24-32 (33-43) | |
| Buckle mounting bolt | 29-57 (39-77) | |
| Pretensioner mounting bolt | 24-32 (32-43) | |
| INCH Lbs. (N.m) | ||
| Dual-stage driver-side air bag module mounting bolts | 79-112 (8.9-12.6) | |
| Dual-stage passenger-side air bag module mounting bolts | 70-104 (7.9-11.7) | |
| Front crash sensor mounting bolt | 79-112 (8.9-12.6) | |
| SAS control module mounting bolts | 79-112 (8.9-12.6) | |
| Side air bag crash sensor bolt | 79-112 (8.9-12.6) | |
| Side air bag module mounting bolt | (1) | |
| Side curtain air bag module mounting bolts | 70-104 (7.9-11.7) | |
| (1) Side air bag module mounting bolt torque specification is not available. | ||
| (1) | Side air bag module mounting bolt torque specification is not available. |
TORQUE SPECIFICATIONS
