FUSE SERVICE CAUTIONS
| CAUTION | Determine and correct the cause of the burnt fuse before replacing it with the specified type. If the fuse is replaced before doing this, it may burn again. |
Scheme 4
Scheme 4: IGNITION SWITCH INSPECTION
Scheme 5
- Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.
Scheme 6
Scheme 6: IGNITION SWITCH REMOVAL/INSTALLATION
- Remove the battery cover. (See BATTERY REMOVAL/INSTALLATION [L3] .)
- Disconnect the negative battery cable.
- Remove the meter hood. (See METER HOOD REMOVAL/INSTALLATION .)
- Remove the column cover. (See COLUMN COVER REMOVAL/INSTALLATION .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 7
Scheme 7: Ignition Switch Connector Removal Note
- Rotate the lever in the direction of the arrow and remove the connector.
Relay type
| Terminal type | Part name |
|---|
| 4 terminals | Type A | Horn relay Front fog light relay Starter relay Drive-by-wire relay A/C relay Fuel pump relay Rear window defroster relay Front blower relay Rear blower relay TNS relay Headlight high relay Headlight low relay Main relay AT main relay |
| Type B | Cooling fan relay |
RELAY TYPE AND PART NAME REFERENCE
Scheme 8
Scheme 9
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
Scheme 10
Scheme 11
- Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
