Interior Trim: Overview Mazda 5 I facelift

Exterior/interior Trim 6 illustrations ~261 words

Scheme 1

Scheme 1: INTERIOR TRIM LOCATION INDEX
Scheme 1: INTERIOR TRIM LOCATION INDEX

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: DASHBOARD REMOVAL/INSTALLATION
Scheme 4: DASHBOARD REMOVAL/INSTALLATION

Scheme 5

Scheme 5
Scheme 5
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-292887-S30644836642008080600000).)
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front door (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-292960-S10388223372008080600000).) Sail garnish (See «SAIL GARNISH REMOVAL/INSTALLATION»(/mazda/5/i-facelift-2007-2010/remont/exteriorinterior-trim/#exterior-trim).) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-292888-S11748287832008080600000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-292888-S14675185142008080600000).) Side panel (passenger's side)(See «SIDE PANEL REMOVAL/INSTALLATION»(ref-292888-S28045845132008080600000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-292888-S04204557052008080600000).) Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-292888-S22395177942008080600000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-292888-S03337365032008080600000).) Undercover Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-292928-S20037409122008080600000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-292888-S42810347612008080600000).) Knee bolster Center panel unit (See «CENTER PANEL MODULE REMOVAL/INSTALLATION»(ref-292927-S19114208722008080600000).) Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-facelift-2007-2010/remont/automatic-trans/#automatic-transaxle-shift-mechanism).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-292926-S08983945512008080600000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-292891-S35675246712008080600000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-292924-S29617705142008080600000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-292888-S19738017082008080600000).) Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-292888-S25932918152008080600000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-292901-S42703079542008080600000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-292891-S35675246712008080600000).) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-292888-S16548083342008080600000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-292890-S30450519742008080600000).)(See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]»(ref-292890-S18303811792008080600000).)(See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]»(ref-292890-S08845262062008080600000).) Rear heater duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION»(ref-292915-S37756334862008080600000).) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-292916-S04731457852008080600000).) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/5/i-facelift-2007-2010/remont/exteriorinterior-trim/#exterior-trim).)
  4. Disconnect the dashboard harness connectors.
  5. Remove in the order indicated in the figure.
  6. Install in the reverse order of removal.

Scheme 6

Scheme 6: Bolt Removal Note
Scheme 6: Bolt Removal Note
