| 1A | Hood latch switch signal | Hood latch switch | Hood open (Hood latch switch off) | 5 | Hood latch switch Related wiring harnesses |
| Hood closed (Hood latch switch on) | 1.0 or less |
| 1B | Tail light power supply | TNS relay | Light switch at TNS position | B+ | TNS relay Related wiring harnesses |
| Light switch at OFF position | 1.0 or less |
| 1C | | | | | |
| 1D | | | | | |
| 1E | Rear window defroster relay control | Rear window defroster relay | Ignition switch at ON | Rear window defroster switch on | 1.0 or less | Rear window defroster relay Related wiring harnesses |
| Rear window defroster switch off | 5 |
| 1F | Power supply | A/C relay | Ignition switch at ON | B+ | A/C relay Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 1G | Brake fluid level signal | Brake fluid level sensor | Ignition switch at ON | Brake fluid level below MIN. | B+ | Brake fluid level sensor Related wiring harnesses |
| Brake fluid level above MIN. | 1.0 or less |
| 1H | Front fog light relay control | Front fog light relay | Front fog light switch on and light switch at TNS position | 1.0 or less | Front fog light relay Related wiring harnesses |
| Front fog light switch off | B+ |
| 11 | | | | | |
| 1J | TNS relay control | TNS relay | Light switch at TNS position | 1.0 or less | TNS relay Related wiring harnesses |
| Light switch at OFF position | B+ |
| 1K | | | | | |
| 1L | Headlight LO relay control | Headlight LO relay | Light switch at headlight position | 1.0 or less | Headlight LO relay Related wiring harnesses |
| Light switch off | B+ |
| 1M | | | | | |
| 1N | Headlight HI relay control | Headlight HI relay | Ignition switch off | Light switch at high position or flash-to-pass | 1.0 or less | Headlight HI relay Related wiring harnesses |
| Other | B+ |
| 10 | IG1 | TR switch AT main relay | Ignition switch at ON | B+ | Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 1P | | | | | |
| 2A | Power supply | Main fuse block | Under any condition | B+ | Related wiring harnesses |
| 2B | Turn light power supply | Main fuse block | Under any condition | B+ | Related wiring harnesses |
| 2C (1) | Headlight (LH) control | Headlight (LH) (low beam) | Light switch at headlight position | 1.0 or less | Headlight (LH) (low beam) Headlight LO relay Related wiring harnesses |
| Light switch off | 1.0 or less |
| Ignition switch ON, light switch off and parking brake released | Approx. 3.6 |
| 2D | Front turn light (LH) control | Front turn light (LH) Front side turn light (LH) | Turn switch (LH) on | Front turn light (LH) flashes | Alternates between 1.0 or less and B+ | Front turn light (LH) Front side turn light (LH) Related wiring harnesses |
| Hazard warning switch on |
| Other | 1.0 or less |
| 2E (1) | Headlight (RH) control | Headlight (RH) (low beam) | Light switch at headlight position | 1.0 or less | Headlight (RH) (low beam) Headlight LO relay Related wiring harnesses |
| Light switch off | 1.0 or less |
| Ignition switch ON, light switch off and parking brake released | Approx. 3.6 |
| 2F | Front turn light (RH) control | Front turn light (RH) Front side turn light (RH) | Turn switch (RH) on | Front turn light (RH) flashes | Alternates between 1.0 or less and B+ | Front turn light (RH) Front side turn light (RH) Related wiring harnesses |
| Hazard warning switch on |
| Other | 1.0 or less |
| 2G | Interior illumination power supply | TNS relay | Light switch at TNS position | B+ | TNS relay Related wiring harnesses |
| Light switch at OFF position | 1.0 or less |
| 2H | Rear washer motor control | Rear washer motor | Ignition switch at ON | Rear washer switch on | 1.0 or less | Rear washer motor Related wiring harnesses |
| Rear washer switch off | B+ |
| 2I | Autostop switch signal | Windshield wiper moto (autostop switch) | Ignition switch at ON | Windshield wiper moving | B+ | Autostop switch (windshield wiper motor) Related wiring harnesses |
| Windshield wiper stopped | 1.0 or less |
| 2J | Power door lock power supply | Main fuse block | Under any condition | B+ | Related wiring harnesses |
| 2K | Windshield wiper motor control | Windshield wiper motor (high speed) | Wiper switch at high position | B+ | Windshield wiper motor Related wiring harnesses |
| Other | 1.0 or less |
| 2L | Windshield wiper motor control | Windshield wiper motor (low speed) | Wiper switch at low position | B+ | Windshield wiper motor Related wiring harnesses |
| Other | 1.0 or less |
| 3A | BCM GND | Body ground | Under any condition: Inspect for continuity to ground. | Continuity detected | Related wiring harnesses |
| 3B | Windshield wiper switch signal (low) | Windshield wiper and washer switch | Ignition switch at ON | Windshield wiper switch at low position | 1.0 or less | Windshield wiper and washer switch Related wiring harnesses |
| Other | B+ |
| 3C | Windshield wiper switch signal (high) | Windshield wiper and washer switch | Ignition switch at ON | Windshield wiper switch at high position | 1.0 or less | Windshield wiper and washer switch Related wiring harnesses |
| Other | B+ |
| 3D | CAN_H | | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | | Related wiring harnesses |
| 3E | Sensitivity adjustment volume (with auto wiper system) | Windshield wiper and washer switch | Ignition switch at ON | Sensitivity adjustment volume turned from + position to - position | 0 --> 0.8 --> 1.5-->2.5--> 2.7 | Windshield wiper and washer switch Related wiring harnesses |
| INT volume (without auto wiper system) | INT volume turned from lowest position to highest position | 0 --> 0.2 --> 0.7-->1.0-->1.4-->1.6-->1.8-->2.0-->2.1-->2.3 |
| 3F | Washer switch signal | Windshield wiper and washer switch | Ignition switch at ON | Washer switch on | B+ | Windshield wiper and washer switch Related wiring harnesses |
| Washer switch off | 1.0 or less |
| 3G | CAN_L | | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | | Related wiring harnesses |
| 3H | Light switch signal (AUTO) | Light switch | Ignition switch at ON | Light switch at AUTO position | 1.0 or less | Light switch Related wiring harnesses |
| Other | B+ |
| 3I | Headlight switch signal (high beam) | Light switch | Light switch at high position or flash-to-pass | 1.0 or less | Light switch Related wiring harnesses |
| Other | B+ |
| 3J | Windshield wiper switch signal (AUTO) (with auto wiper system) | Windshield wiper switch | Ignition switch at ON | Windshield wiper switch at AUTO position | 1.0 or less | Windshield wiper switch Related wiring harnesses |
| Other | B+ |
| Windshield wiper switch signal (INT) (without auto wiper system) | Windshield wiper switch at INT position | 1.0 or less |
| Other | B+ |
| 3K | Rear wiper switch signal (on) | Rear wiper and washer switch | Ignition switch at ON | Rear wiper switch at ON position | 1.0 or less | Rear wiper and washer switch Related wiring harnesses |
| Other | B+ |
| 3L | Headlight switch signal | Light switch | Light switch at headlight position | 1.0 or less | Light switch Related wiring harnesses |
| Light switch at OFF position | B+ |
| 3M | Rear wiper switch signal (INT) | Rear wiper and washer switch | Ignition switch at ON | Rear wiper switch at INT position | 1.0 or less | Rear wiper and washer switch Related wiring harnesses |
| Other | B+ |
| 3N | | | | | |
| 3O | TNS signal | Light switch | Light switch at TNS position | 1.0 or less | Light switch Related wiring harnesses |
| Light switch at OFF position | B+ |
| 3P | Rear window defroster signal (with manual A/C) | Climate control unit | Rear window defroster switch is pressed | 1.0 or less | Climate control unit Related wiring harnesses |
| Rear window defroster switch is released | B+ |
| 3Q | Turn switch input (RH) | Turn switch | Ignition switch at ON | Turn switch at right position | 1.0 or less | Turn switch Related wiring harnesses |
| Other | B+ |
| 3R | Front fog light switch signal | Front fog light switch | Front fog light switch on | 1.0 or less | Fog light switch Related wiring harnesses |
| Front fog light switch off | B+ |
| 3S | A/C operation signal (with manual A/C) | Climate control unit | A/C operating | 1.0 or less | Climate control unit Related wiring harnesses |
| A/C not operating | 5 |
| 3T | Turn switch input (LH) | Turn switch | Ignition switch at ON | Turn switch at left position | 1.0 or less | Turn switch Related wiring harnesses |
| Other | B+ |
| 3U | Power supply | Fuse block | Ignition switch at ON | B+ | Ignition switch Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 3V | Rear window defroster indicator control (with manual A/C) | Climate control unit | Rear window defroster on | 1.0 or less | Climate control unit Related wiring harnesses |
| Rear window defroster off | B+ |
| 3W | Hazard warning switch signal | Hazard warning switch | Hazard warning switch on | 1.0 or less | Hazard warning switch Related wiring harnesses |
| Hazard warning switch off | B+ |
| 3X | Power supply | Fuse block | Ignition switch at ON | B+ | Ignition switch Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 3Y | Horn control | Horn relay | Transmitter LOCK button is pressed twice within 5 s. | B+ --> 1.0 or less --> B+ | Horn relay Related wiring harnesses |
| Other | B+ |
| 3Z | Ignition key illumination control | Ignition key illumination | Ignition switch off and driver-side door opened. | 1.0 or less | Ignition key illumination bulb Related wiring harnesses |
| 15 s or more after all doors closed. | B+ |
| 3AA | Rear washer switch signal | Rear wiper and washer switch | Ignition switch at ON | Rear washer switch on | 1.0 or less | Rear wiper and washer switch Related wiring harnesses |
| Rear washer switch off | B+ |
| 3AB | Serial communication | Keyless receiver | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | | Keyless receiver Related wiring harnesses |
| 3AC | | | | | |
| 3AD | Key reminder switch signal | Steering lock unit (with advanced keyless system) Ignition switch (with keyless entry system) | Key inserted | B+ | Steering lock unit (with advanced keyless system) Ignition switch(with keyless entry system) Related wiring harnesses |
| Key removed | 1.0 or less |
| 4A | Windshield wiper motor power supply | Ignition switch Fuse block | Ignition switch at ON | B+ | Ignition switch Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 4B | Power supply | Fuse block | Ignition switch at ON | B+ | Ignition switch Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 4C | Illumination control | Illumination bulb | Light switch at TNS position | B+ | Illumination bulb Related wiring harnesses |
| Light switch at OFF position | 1.0 or less |
| 4D | Key reminder switch, ignition key illumination power supply | Key reminder switch Ignition key illumination | Under any condition | B+ | Related wiring harnesses |
| 4E | GND | Body ground | Under any condition: Inspect for continuity to ground. | Continuity detected | Related wiring harnesses |
| 4F | | | | | |
| 5A | Liftgate latch switch signal | Liftgate latch switch | Liftgate is open. (Liftgate latch switch on) | 1.0 or less | Liftgate latch switch Related wiring harnesses |
| Liftgate is closed. (Liftgate latch switch off) | B+ |
| 5B | | | | | |
| 5C | Sliding door switch signal | Sliding door switches | Any sliding door open (Sliding door switch on) | 1.0 or less | Sliding door switches Related wiring harnesses |
| All sliding doors closed (Sliding door switch off) | B+ |
| 5D | | | | | |
| 5E | Front door latch switch (passenger-side) signal | Front door latch switch (passenger-side) | Front door (passenger-side) open (Front door latch switch (passenger-side) off) | B+ | Front door latch switch (passenger-side) Related wiring harnesses |
| Front door (passenger-side) closed (Front door latch switch (passenger-side) on) | 1.0 or less |
| 5F | | | | | |
| 5G | Front door latch switch (driver-side) signal | Front door latch switch (driver-side) | Front door (driver-side) open (Front door latch switch (driver-side) off) | B+ | Front door latch switch (driver-side) Related wiring harnesses |
| Front door (driver-side) closed (Front door latch switch (driver-side) on) | 1.0 or less |
| 5H | | | | | |
| 5I | Lock/unlock signal | Door lock switch | Door lock switch is pressed to lock. | 2.5 | Door lock switch Related wiring harnesses |
| Door lock switch is pressed to unlock. | 1.0 or less |
| Other | 5 |
| 5J | | | | | |
| 5K | Parking brake switch signal | Parking brake switch | Ignition switch at ON | Parking brake switch on | 1.0 or less | Parking brake switch Related wiring harnesses |
| Parking brake switch off | B+ |
| 5L | | | | | |
| 5M | Wiper or headlight operation request | Rain sensor | Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. | | Rain sensor Related wiring harnesses |
| 5N | Power supply | Sunroof unit Sunroof switch | Ignition switch at ON | B+ | Sunroof unit Sunroof switch Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 5O | Unlock input (Sliding door lock-link switch) | Sliding door lock-link switch | All sliding doors locked | 5 | Sliding door lock-link switch Related wiring harnesses |
| Any sliding door unlocked | 1.0 or less |
| 5P | Seat weight sensor control module power supply (IG2) | Seat weight sensor control module | Ignition switch at ON | B+ | Seat weight sensor control module Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 5Q | Unlock input (Driver-side door key cylinder switch) | Driver-side door key cylinder switch | At the moment key cylinder is unlocked | 1.0 or less | Driver-side door key cylinder switch Related wiring harnesses |
| Other | 5 |
| 5R | Tail light control | Tail light | Light switch at TNS position | B+ | Tail light Related wiring harnesses |
| Light switch at OFF position | 1.0 or less |
| 5S | Lock input (Driver-side door key cylinder switch) | Driver-side door key cylinder switch | At the moment key cylinder is locked | 1.0 or less | Driver-side door key cylinder switch Related wiring harnesses |
| Other | 5 |
| 5T | Power supply | Rain sensor | Ignition switch at ON | B+ | Rain sensor Related wiring harnesses |
| Ignition switch off | 1.0 or less |
| 5U | Lock input (Driver-side door lock-link switch) | Driver-side door lock-link switch | Driver-side door locked | 1.0 or less | Driver-side door lock-link switch Related wiring harnesses |
| Driver-side door unlocked | 5 |
| 5V | Rear turn light (RH) control | Rear turn light (RH) | Turn switch (RH) on | Rear turn light (RH) flashes | Alternates between 1.0 or less and B+ | Rear turn light (RH) Related wiring harnesses |
| Hazard warning switch on |
| Other | 1.0 or less |
| 5W | Unlock input (Driver-side door lock-link switch) | Driver-side door lock-link switch | Driver-side door locked | 5 | Driver-side door lock-link switch Related wiring harnesses |
| Driver-side door unlocked | 1.0 or less |
| 5X | Rear turn light (LH) control | Rear turn light (LH) | Turn switch (LH) on | Rear turn light (LH) flashes | Alternates between 1.0 or less and B+ | Rear turn light (LH) Related wiring harnesses |
| Hazard warning switch on |
| Other | 1.0 or less |
| 6A | Door lock control | Door lock actuator | Door lock actuator locking | 1.0 or less -->B+-->1.0 or less | Door lock actuator Related wiring harnesses |
| Other | 1.0 or less |
| 6B | Door unlock control | Door lock actuator | Door lock actuator unlocking | 1.0 or less-->B+-->1.0 or less | Door lock actuator Related wiring harnesses |
| Other | 1.0 or less |
| 6D | Driver-side door unlock control | Driver-side door lock actuator | Driver-side door lock actuator unlocking | 1.0 or less-->B+-->1.0 or less | Driver-side door lock actuator Related wiring harnesses |
| Other | 1.0 or less |
| 6F | | | | | |
| 6G | Rear wiper control | Rear wiper motor | Rear wiper moving | 1.0 or less | Rear wiper motor Related wiring harnesses |
| Rear wiper stopped | B+ |
| 6H | | | | | |
| 6I | Interior light control | Map light Interior light | Within 5 min after any door is opened. | 1.0 or less | Map light Interior light Related wiring harnesses |
| 5 min or more after any door is opened. | B+ |
| All doors closed | B+ |
| 6J | Interior light power supply | Map light Interior light Cargo compartment light | Under any condition | B+ | Related wiring harnesses |
| (1) With DRL |
