SYMPTOM TROUBLESHOOTING CHART [POWER WINDOW SYSTEM]
| No. | Malfunction symptom |
|---|---|
| 1 | NO.1 THE AUTO OPEN FUNCTION ON THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM] |
| 2 | NO.2 THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM] |
| 3 | NO.3 ALL POWER WINDOWS OTHER THAN DRIVER'S SIDE DO NOT OPERATE USING THE POWER WINDOW SUBSWITCH [POWER WINDOW SYSTEM] |
| 4 | NO.4 ALL POWER WINDOWS OTHER THAN DRIVER'S SIDE DO NOT OPERATE USING THE POWER WINDOW MAIN SWITCH [POWER WINDOW SYSTEM] |
| 5 | NO.5 ALL POWER WINDOWS ARE INOPERATIVE [POWER WINDOW SYSTEM] |
| 6 | NO.6 ABNORMAL NOISE WHILE THE DOOR GLASS IS OPENING OR CLOSING [POWER WINDOW SYSTEM] |
SYMPTOM TROUBLESHOOTING CHART
Scheme 3
![Scheme 3: POWER WINDOW SYSTEM WIRING DIAGRAM [POWER WINDOW SYSTEM]](https://i.diagnostdata.com/repair/cc/ccf81412411ac3ecfb6bdf04276660c92efb0181184ae8e4040a78b7efbe2a8c.webp)
Manual Open/close Function Inspection
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Operate the power window using the manual open/close function on the power window main switch. Does the power window operate properly? | Yes | Go to the next step. |
| No | Inspect the power window main switch and the wiring harness. Repair or replace malfunctioning parts. | ||
| 2 | Set the power cut switch to the UNLOCK position. Operate the power window using the power window subswitch. Does the power window operate properly? | Yes | Go to the next step. |
| No | Inspect the power window subswitch and the wiring harness. Repair or replace malfunctioning parts. | ||
| 3 | Set the power cut switch to the LOCK position. Operate all power windows other than the driver side. Does the power window operate properly? | Yes | Inspect the power cut switch and the wiring harness. Replace the power window main switch. |
| No | Manual open/close function is normal. Perform the auto open/close function inspection. | ||
DIAGNOSTIC PROCEDURE CHART
Auto Open Function (Driver's Side) Inspection
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Operate the power window using the auto open function on the power window main switch. Does the power window operate properly? | Yes | Go to the next step. |
| No | Go to NO.1 THE AUTO OPEN FUNCTION ON THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM] . | ||
| 2 | Operate the power window main switch to the close position while the power window is opening. Does the power window operation stop? | Yes | Auto open function is normal. |
| No | Replace the power window main switch (power window control unit is malfunctioning.) | ||
DIAGNOSTIC PROCEDURE CHART
Diagnostic procedure
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Perform the Auto Open Function (Driver's side) Inspection on POWER WINDOW SYSTEM PRELIMINARY INSPECTION. (See POWER WINDOW SYSTEM PRELIMINARY INSPECTION [POWER WINDOW SYSTEM] .) Is the malfunctioning part detected? | Yes | Repair or replace malfunctioning part according to inspection results. |
| No | Go to NO.2 THE DRIVER'S SIDE POWER WINDOW IS INOPERATIVE [POWER WINDOW SYSTEM] . | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Does the LED on the power window main switch illuminate? | Yes | Go to Step 6. |
| No | Go to the next step. | ||
| 2 | Operate all power windows other than the driver's side window using the power window main switch. Does the power window operate properly? | Yes | Go to the next step. |
| No | Inspect for an open or short circuit in the following wiring harnesses. Inspect the connector connections (damage/pulled-out pins, corrosion): P/W 30 A fuse-Power window main switch terminal B Power window main switch terminal M-ground. Repair or replace if necessary. | ||
| 3 | Is the P/W 30 A fuse normal? | Yes | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) |
| No | Inspect the following: Short circuit in B+ power supply wiring harness Short circuit in power window motor Repair or replace if necessary. Replace with the appropriate standard fuse. Then, go to the next step. | ||
| 4 | Measure the voltage at the power window main switch, (power window motor output terminal) while operating the power window using the power window main switch. Is the voltage B+? (Open: terminal A/close: terminal C) | Yes | Go to the next step. |
| No | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) | ||
| 5 | Measure the voltage at the power window motor (battery power supply terminal) while operating the power window. Is the voltage B+? (Open: terminal E/close: terminal F) | Yes | Go to the next step. |
| No | Inspect for an open or short circuit in the wiring harness between the power window main switch and the power window motor. Inspect the power window main switch and power window motor connector connections, (damage/pulled-out pins, corrosion) Repair or replace if necessary. | ||
| 6 | Operate the driver's side power window using the power window main switch. Does the power window motor operate (rotate)? CAUTION: If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect. | Yes | Go to the next step. |
| No | Replace the power window motor. (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .) | ||
| 7 | Remove the door glass from the carrier plate. Make sure that the door glass moves smoothly using your hand. Does the door glass move smoothly? | Yes | Replace the power window regulator. (See FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION .) |
| No | Inspect for a bent regulator guide or other possible malfunction. If normal, replace the door glass run-channel. | ||
| CAUTION |
|---|
| If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect. |
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Set the power cut-switch to the UNLOCK position. Measure the voltage at the power window subswitch terminal B. Is the voltage B+? | Yes | Replace the power window subswitch. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .) |
| No | Inspect for an open or short circuit in the wiring harness between the power window main switch and the power window subswitch. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Set the power cut-switch to the UNLOCK position. Operate all power windows other than the driver's side using the power window main switch. Do any power windows operate? | Yes | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) |
| No | Inspect for an open or short circuit in the power window main switch wiring harness (battery power supply). Inspect the power window main switch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. | ||
DIAGNOSTIC PROCEDURE CHART
| STEP | INSPECTION | ACTION | |
|---|---|---|---|
| 1 | Turn the ignition switch to the ON position. Set the power cut-off switch to the UNLOCK position. Inspect the power window system operation again. Does the system operate properly? | Yes | System is now normal (power cut-off switch is not set properly.) |
| No | Go to the next step. | ||
| 2 | Operate all power windows other than driver's side window using the power window main switch. Does any power window operate? | Yes | Go to Step 5. |
| No | Go to the next step. | ||
| 3 | Operate the driver's side power window using the power window main switch. Does the power window operate? | Yes | Go to the next step. |
| No | Inspect for an open circuit in the wiring harness between the power window main switch and the body ground. Inspect the power window main switch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary | ||
| 4 | Is the P/W 30 A fuse normal? | Yes | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) |
| No | Replace with the appropriate standard fuse. If the fuse is melted, inspect the wiring harness for a short to ground. Repair or replace the wiring harness, then replace the fuse. | ||
| 5 | Identify the inoperative power window. Measure the voltage at the suspect power window motor (battery power supply) while operating the power window motor using the suspect power window subswitch Is the voltage B+? (Open: terminal E/close: terminal F) | Yes | Go to the next step. |
| No | Go to Step 8. | ||
| 6 | Operate the power window using the power window subswitch Does the power window motor operate (rotate)? CAUTION: If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect. | Yes | Go to the next step. |
| No | Replace the power window motor. (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .) | ||
| 7 | Remove the door glass from the carrier plate. Make sure that the door glass moves smoothly using your hand. Does the door glass move smoothly? | Yes | Replace the power window regulator guide. |
| No | Inspect for a bent regulator guide or other possible malfunction. If normal, replace the glass run channel. | ||
| 8 | Measure the voltage at the power window subswitch (power window motor output) while operating the power window subswitch. Is the voltage B+? (Open: terminal E/close: terminal C) | Yes | Inspect for an open or short circuit in the wiring harness between the power window subswitch and power window motor. Inspect the power window subswitch and power window motor connector connections (damage/pulled-out pins, corrosion). Repair or replace if necessary. |
| No | Go to the next step. | ||
| 9 | NOTE: Do not operate the power window subswitch during the following inspection. Inspect the continuity between power window subswitch terminal D (vehicle harness-side) and ground. Is there continuity? | Yes | Go to the next step. |
| No | Inspect for an open or short circuit in the power window subswitch wiring harness. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. Then go to Step 12. | ||
| 10 | NOTE: Do not operate the power window subswitch during the following inspection. Inspect the continuity between power window subswitch terminal E and ground. Is there continuity? | Yes | Replace the power window subswitch. (See POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION .) |
| No | Inspect for an open or short circuit in the power window subswitch wiring harness. Inspect the power window subswitch connector connection, (damage/pulled-out pins, corrosion) Repair or replace if necessary. Then go to the next step. | ||
| 11 | NOTE: Do not operate the power window main switch during the following inspection. Inspect the continuity between power window main switch terminal (up-side K, N, F) and ground. Is there continuity? | Yes | Go to the next step. |
| No | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) | ||
| 12 | NOTE: Do not operate the power window main switch during the following inspection. Inspect the continuity between power window main switch terminal (down-side I, L, D) and ground. Is there continuity? | Yes | Inspect for an open or short circuit in the wiring harness between the power window main switch and power window subswitch. Inspect the power window main switch and subswitch connector connections, (damage/pulled-out pins, corrosion) Repair or replace if necessary. |
| No | Replace the power window main switch. (See POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION .) | ||
| CAUTION |
|---|
| If the power window motor temperature is high, the motor may not rotate due to the motor internal bimetal function. Leave it untouched for about 3 min to cool it down, then reinspect. |
| NOTE |
|---|
| Do not operate the power window subswitch during the following inspection. |
| NOTE |
|---|
| Do not operate the power window subswitch during the following inspection. |
| NOTE |
|---|
| Do not operate the power window main switch during the following inspection. |
| NOTE |
|---|
| Do not operate the power window main switch during the following inspection. |
DIAGNOSTIC PROCEDURE CHART
| Noise type | Time of occurrence | Possible cause | Location of noise | Action |
|---|---|---|---|---|
| Clanking noise | Door glass begins to move | Insufficiently tightened installation screw between the door glass and carrier plate. | Between door glass lower edge and carrier plate. | Securely tighten the installation screw. |
| Groaning noise (Sound increases due to use) | While door glass is operating | Vibration caused by wear on the resin part from cable twisting due to use of the power window regulator. NOTE: Noise does not occur if a roller is equipped to power window regulator resin part. | Power window regulator | Replace the power window regulator (See FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION .) (See REAR POWER WINDOW REGULATOR REMOVAL/INSTALLATION .) |
| Whining noise | Gear inside power window motor is deformed due to use. | Gear in power window motor | Replace the power window motor (See POWER WINDOW MOTOR REMOVAL/INSTALLATION .) | |
| Clicking noise (Periodic noise) |
| NOTE |
|---|
| Noise does not occur if a roller is equipped to power window regulator resin part. |
